Cold-Drawn Hastelloy C276 Tube with Polished Surface and OD 6-630mm for Flue-Gas Desulfurization
Cold-Drawn Hastelloy C276 Tube with Polished Surface and OD 6-630mm for Flue-Gas Desulfurization
Cold-Drawn Hastelloy C276 Tube with Polished Surface and OD 6-630mm for Flue-Gas Desulfurization
Cold-Drawn Hastelloy C276 Tube with Polished Surface and OD 6-630mm for Flue-Gas Desulfurization
Cold-Drawn Hastelloy C276 Tube with Polished Surface and OD 6-630mm for Flue-Gas Desulfurization
Cold-Drawn Hastelloy C276 Tube with Polished Surface and OD 6-630mm for Flue-Gas Desulfurization
Cold-Drawn Hastelloy C276 Tube with Polished Surface and OD 6-630mm for Flue-Gas Desulfurization
Cold-Drawn Hastelloy C276 Tube with Polished Surface and OD 6-630mm for Flue-Gas Desulfurization
Cold-Drawn Hastelloy C276 Tube with Polished Surface and OD 6-630mm for Flue-Gas Desulfurization
Cold-Drawn Hastelloy C276 Tube with Polished Surface and OD 6-630mm for Flue-Gas Desulfurization
Cold-Drawn Hastelloy C276 Tube with Polished Surface and OD 6-630mm for Flue-Gas Desulfurization
Cold-Drawn Hastelloy C276 Tube with Polished Surface and OD 6-630mm for Flue-Gas Desulfurization
Cold-Drawn Hastelloy C276 Tube with Polished Surface and OD 6-630mm for Flue-Gas Desulfurization
Cold-Drawn Hastelloy C276 Tube with Polished Surface and OD 6-630mm for Flue-Gas Desulfurization
Specifications
Certification :
AISI, ASTM
MOQ :
50 kg
Price :
US $30-40 / kg
Model NO. :
C276
Shape :
Round
Technique :
Cold-Drawing
Surface Treatment :
Polished
OD Range :
6-630mm
Production Capacity :
50000kgs
OD Size :
5-420mm
Wall Thickness :
0.5-50mm
Length :
max12000mm
Nickel Content :
Bal.
Chromium Content :
14.5-16.5%
Molybdenum Content :
15.0-17.0%
Carbon Content :
Max 0.010%
Ultimate Tensile Strength :
690 MPa
Yield Strength :
283 MPa
Description
Hastelloy C276 Round Tube
High-performance nickel alloy steel pipes designed for demanding industrial applications requiring exceptional corrosion resistance.
Product Specifications
  • Type: Nickel Alloy Steel Pipes
  • Technique: Cold-finished, Hot-finished
Primary Applications
  • Equipment for flue-gas desulfurization plants
  • Organic chloride process equipment
Dimensional Specifications
Parameter Range
Outside Diameter (OD) 5-420mm
Wall Thickness (WT) 0.5-50mm
Length Maximum 12000mm
Chemical Composition
Element Minimum % Maximum %
Nickel (Ni) Balance Balance
Chromium (Cr) 14.5 16.5
Manganese (Mn) - 1.0
Molybdenum (Mo) 15.0 17.0
Carbon (C) - 0.010
Silicon (Si) - 0.08
Iron (Fe) 4.0 7.0
Mechanical Properties
Property Minimum Value
Ultimate Tensile Strength 100 KSi (690 MPa)
Yield Strength (0.2% Offset) 41 KSi (283 MPa)
Elongation in 2 inches 40%
Product Gallery
Cold-Drawn Hastelloy C276 Tube with Polished Surface and OD 6-630mm for Flue-Gas Desulfurization Cold-Drawn Hastelloy C276 Tube with Polished Surface and OD 6-630mm for Flue-Gas Desulfurization Cold-Drawn Hastelloy C276 Tube with Polished Surface and OD 6-630mm for Flue-Gas Desulfurization
