Specifications
Certification :
AISI, ASTM
MOQ :
50 kg
Price :
US $30-35 / kg
Model NO. :
Hastelloy C-22
Shape :
Flat
Technique :
Cold-Drawing
Surface Treatment :
Polished
Specification :
OD 6-630mm
Production Capacity :
50000kgs
Nickel Content :
balance
Chromium Content :
20.00-22.50%
Molybdenum Content :
12.50-14.50%
Iron Content :
2.00-6.00%
Tungsten Content :
2.50-3.00%
Cobalt Content :
≤2.50%
Carbon Content :
≤0.10%
Silicon Content :
≤0.08%
Manganese Content :
≤0.50%
Description
Hastelloy C-22 Plate & Round Bar, Tube
Hastelloy C-22 Nickel Base Corrosion Resistant Alloy Seamless Tube N06022
Introduction

Hastelloy C-22 is one of the most widely used nickel-chromium-molybdenum-tungsten alloys. It offers superior resistance to both uniform and local corrosion, making it suitable for various mixed industrial chemicals. HC-22 provides better corrosion resistance than other Ni-Cr-Mo alloys, including C-276, C-4, and 625. C-22 alloys also feature excellent weldability.

Hastelloy C-22 / N06022 Chemical Composition
Element Composition (%)
Nickel (Ni) Balance
Chromium (Cr) 20.00-22.50
Molybdenum (Mo) 12.50-14.50
Iron (Fe) 2.00-6.00
Tungsten (W) 2.50-3.00
Cobalt (Co) ≤2.50
Carbon (C) ≤0.10
Silicon (Si) ≤0.08
Manganese (Mn) ≤0.50
Phosphorus (P) ≤0.02
Vanadium (V) ≤0.35
Inspection and Test Procedures
  1. 100% PMI, Spectro Chemical Analysis Test for Raw Material
  2. 100% Dimension & Visual Examination
  3. Mechanical Properties Test including Tension Test, Flaring Test (for Seamless tube/pipe), Flange Test (for Welded Pipe & Tube), Hardness Test, Reversed Flattening Test
  4. 100% Hydrostatic Test or 100% Non-Destructive Test (ET or UT)
  5. Radiographic Test for Welded Pipe (in accordance with specification, or as agreed between purchaser and vendor)
  6. Straightness Test (optional)
  7. Roughness Test (optional)
  8. Intergranular Corrosion Test (optional)
  9. Impact Test (optional)
  10. Grain Size Determinations (optional)

Notes: All test and inspection results must be documented in reports according to standard specifications.
