Cold Rolled Monel 400 Sheet Plate with Bright Surface ASTM B127 Nickel Alloy
Cold Rolled Monel 400 Sheet Plate with Bright Surface ASTM B127 Nickel Alloy
Cold Rolled Monel 400 Sheet Plate with Bright Surface ASTM B127 Nickel Alloy
Cold Rolled Monel 400 Sheet Plate with Bright Surface ASTM B127 Nickel Alloy
Cold Rolled Monel 400 Sheet Plate with Bright Surface ASTM B127 Nickel Alloy
Cold Rolled Monel 400 Sheet Plate with Bright Surface ASTM B127 Nickel Alloy
Cold Rolled Monel 400 Sheet Plate with Bright Surface ASTM B127 Nickel Alloy
Cold Rolled Monel 400 Sheet Plate with Bright Surface ASTM B127 Nickel Alloy
Cold Rolled Monel 400 Sheet Plate with Bright Surface ASTM B127 Nickel Alloy
Cold Rolled Monel 400 Sheet Plate with Bright Surface ASTM B127 Nickel Alloy
Cold Rolled Monel 400 Sheet Plate with Bright Surface ASTM B127 Nickel Alloy
Cold Rolled Monel 400 Sheet Plate with Bright Surface ASTM B127 Nickel Alloy
Specifications
MOQ :
50 kg
Price :
US $28.5-43.5 / kg
Model Number :
Monel 400
Shape :
Flat
Technique :
Cold Rolled
Surface Treatment :
Bright
Specification :
1220*2440, 1500*3000, 1500*6000, 2000*6000mm
Production Capacity :
50000kgs
Size Range :
15NB to 150NB In
Standards :
ASTM B 127 / ASME SB 127
Finish :
Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN
Grades :
UNS N04400, UNS N05500
Tensile Strength :
70-85 ksi
Yield Strength :
28-50 ksi
Elongation :
50-35%
Hardness :
60-76 HRB
Chemical Composition :
C: .3 max, MN: 2.0 max, P: .02 max, S: .024 max, Si: .5 max, Ni: 63.0 max, Cu: 28-34 max, Fe: 2.5 max
Description
Monel 400 Sheet Plate 2500 X 1250 * 3mm UNS N04400
High-quality Monel 400 plates, sheets, and coils manufactured to international standards for demanding industrial applications.
Product Overview
We are leading manufacturers, suppliers, and exporters of Monel 400 and Monel K500 plates, sheets, and coils in Mumbai, India. Our products are manufactured using premium raw materials and comply with national and international standards including ASTM B127 / ASME SB 127.
Technical Specifications
Size Range 15NB to 150NB
Standards ASTM B127 / ASME SB127
Types Available Sheet, Plates, Coils, Flat, Strips, Profile, Blank, Circle, Ring
Surface Finish Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN
Forms Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange)
Material Grades
Material Werkstoff Nr. UNS JIS AFNOR BS GOST EN
Monel 400 2.4360 N04400 NW 4400 NU-30M NA 13 МНЖМц 28-2,5-1,5 NiCu30Fe
Monel K500 2.4375 N05500 - - - - -
Chemical Composition - Alloy 400 (UNS N04400)
Element Content (%)
C (Carbon) 0.3 max
MN (Manganese) 2.0 max
P (Phosphorus) 0.02 max
S (Sulfur) 0.024 max
Si (Silicon) 0.5 max
Ni (Nickel) 63.0 max
Cu (Copper) 28-34 max
Fe (Iron) 2.5 max
Mechanical Properties
Condition Tensile (ksi) 0.2% Yield (ksi) Elongation (%) Hardness (HRB)
Annealed 70-85 28-50 50-35 60-76
Available Product Types
  • Monel 400 / K500 Plates
  • Monel 400 / K500 Sheets
  • Monel 400 / K500 Shim Sheet
  • Monel 400 / K500 Perforated Sheet
  • Monel 400 / K500 Chequered Plate
  • Monel 400 / K500 Rolls
  • Monel 400 / K500 Ring
  • Monel 400 / K500 Circles
  • Monel 400 / K500 Coils
  • Monel 400 / K500 Strips
  • Monel 400 / K500 Flat
  • Monel 400 / K500 Blank
  • Monel 400 / K500 Profile
  • Monel 400 / K500 Foils
Industrial Applications
Our Monel sheets, plates, and coils are widely used in various industries including Chemical Processing, Fats & Fertilizers, Sugar Mills & Distilleries, Cement Industries, Ship Building, Paper Industries, and other demanding applications requiring corrosion resistance and durability.
