Specifications
Certification :
ISO
MOQ :
50 kg
Price :
US $25-60.5 / kg
Model NO. :
C22
Shape :
Round
Technique :
Cold-Drawing
Surface Treatment :
Pickling
Specification :
OD 6-630mm
Production Capacity :
50000kgs
Density :
8.69 g/cm3
Melting Range :
1325-1370ºC
Outer Diameter :
1/8" ~ 8"
Wall Thickness :
SCH 5 / SCH 10 / SCH 40 / SCH 80 / SCH 160
Length :
Upto 6 Meters
Nickel Content :
balance
Chromium Content :
20-22.5%
Molybdenum Content :
12.5-14.5%
Tungsten Content :
2.5-3.5%
Description
Hastelloy C22 Seamless Pipes & Tubes
Premium nickel-chromium-molybdenum alloy pipes offering exceptional corrosion resistance for demanding industrial applications.
Product Specifications
Alloy Designations: UNS N06022, DIN 2.4602, NiCr21Mo14W
Standards: ASTM B622, ASME SB622, ASTM B619, ASTM B626
Manufacturer: GE MING SHENG - Certified supplier with full 3.1 certification
Chemical Composition
ElementMin (%)Max (%)
NiBalance-
Cr2022.5
Mo12.514.5
Fe26
W2.53.5
C-0.015
Mn-0.5
Si-0.08
P-0.02
S-0.02
Physical Properties
Density8.69 g/cm³
Melting Range1325-1370°C
Key Features
  • Superior corrosion resistance compared to C-276, C-4, and Inconel 625
  • Excellent resistance to pitting, crevice corrosion, and stress corrosion cracking
  • Outstanding performance in oxidizing aqueous media including wet chlorine
  • Optimal resistance in mixed reducing and oxidizing conditions
  • Resists grain boundary precipitation in weld heat-affected zones
  • Suitable for as-welded condition in most chemical process applications
Applications
Chemical processing (acetic acid, acetic anhydride), pickling operations, cellophane manufacturing, chlorination systems, electro-galvanizing rolls, flue gas scrubber systems, geothermal wells, HF furnace scrubbers, incineration scrubbers, nuclear fuel reprocessing, pesticide production, phosphoric acid production, heat exchangers, and sulfur dioxide cooling towers.
Available Sizes & Grades
TypeOuter DiameterWall ThicknessLength
NB Sizes (Stock)1/8" ~ 8"SCH 5/10/40/80/160Up to 6 Meters
Seamless (Custom)5.0mm ~ 203.2mmAs requiredUp to 6 Meters
Welded (Stock + Custom)5.0mm ~ 1219.2mm1.0 ~ 15.0 mmUp to 6 Meters
Hastelloy Alloy Comparison
AlloyC%Cr%Mo%Fe%Ni%
Hastelloy B-20.02126-302Balance
Hastelloy C-40.01514-1814-173Balance
Hastelloy C-2760.0214-16.515-174-7Balance
Hastelloy G0.0521-23.55.5-7.518-21Balance
Hastelloy X-21-238-1017-20Balance
Seamless Hastelloy C22 Pipe with Cold-Drawing Technique and Pickling Surface Treatment in OD 6-630mm Seamless Hastelloy C22 Pipe with Cold-Drawing Technique and Pickling Surface Treatment in OD 6-630mm
Note: Hastelloy and C-22 are registered trademarks of Haynes International, Inc. Inconel is a registered trademark of the Special Metals Corporation group of companies.
