High Strength AISI SAE 1045 S45c Hot Rolled Carbon Steel Round Bar
High Strength AISI SAE 1045 S45c Hot Rolled Carbon Steel Round Bar
High Strength AISI SAE 1045 S45c Hot Rolled Carbon Steel Round Bar
High Strength AISI SAE 1045 S45c Hot Rolled Carbon Steel Round Bar
High Strength AISI SAE 1045 S45c Hot Rolled Carbon Steel Round Bar
High Strength AISI SAE 1045 S45c Hot Rolled Carbon Steel Round Bar
High Strength AISI SAE 1045 S45c Hot Rolled Carbon Steel Round Bar
High Strength AISI SAE 1045 S45c Hot Rolled Carbon Steel Round Bar
High Strength AISI SAE 1045 S45c Hot Rolled Carbon Steel Round Bar
High Strength AISI SAE 1045 S45c Hot Rolled Carbon Steel Round Bar
High Strength AISI SAE 1045 S45c Hot Rolled Carbon Steel Round Bar
High Strength AISI SAE 1045 S45c Hot Rolled Carbon Steel Round Bar
Specifications
MOQ :
1 Ton
Price :
US $590-1,050 / Ton
Model NO. :
SAE 1045 s45c
Surface Treatment :
Polished
Alloy :
Non-alloy
Specification :
OD 6-630mm
Carbon Content :
0.42-0.5
Silicon Content :
0.17-0.37
Manganese Content :
0.5-0.8
Chromium Content :
≤0.25
Phosphorus Content :
≤0.035
Sulfur Content :
≤0.035
Nickel Content :
≤0.3
Copper Content :
≤0.25
Tensile Strength :
600 N/mm2
Yield Strength :
355 N/mm2
Hardness :
229 HB
Description
High Strength High Carbon AISI SAE 1045 S45C Steel Round Bar Hot Rolled
Product Overview

AISI 1045 steel round bar is a high carbon steel under American standard, classified as quenching and tempering steel with high strength properties. This alloy steel is available in various forms including hot rolled round bars and square bars, cold-drawing bars, and forged bars.

Applications

AISI 1045 round bar is widely used for manufacturing moving parts requiring high strength, including:

  • Plunger of air compressor and pump
  • Rolled shaft and connecting rod
  • Endless screw and gear rack
  • Dowel of heavy machines
  • Crank axle and machine tool shaft
  • Transmission shaft and wear resistant parts

Commonly used in quenching and tempering and normalizing delivery states. After high-frequency quenching or shot peening, it can be applied to produce wear resistant components.

Chemical Composition
Grade C Si Mn Cr P S Ni Cu
AISI 1045 0.42-0.5 0.17-0.37 0.5-0.8 ≤0.25 ≤0.035 ≤0.035 ≤0.3 ≤0.25
Mechanical Properties
Grade Delivery State T.S. (N/mm²) Min Y.S. (N/mm²) Min A,% Min Z,% Min Hardness, HB max Forging Ratio Grain Size (level) Nonmetal Ratio
AISI 1045 Hot rolled, forged, or heat treatment 600 355 16 40 229 | 197 ≥ 4:1 ≥ 6 ≤ 2.0
Available Steel Grades
Steel Series Representative Steel Type
Carbon Steel series AISI 1020, 1045, A36, S355JR, S355JO
Petroleum machinery series AISI 4150, AISI 4140, AISI 4130, 30CrMo, 4145H
Tool mold series 1.2714, 5CrMnMo, 5CrNiMoV, 1.2738, 1.2311, 1.2312
Bearing series 52100, GCr15, SUJ2
Marine series 4140, 42CrMo, SCM440, 709M40
Car series SAE 8620, 20CrNiMo, SNCM220
Heavy-duty transmission series 40CrNiMo, SNCM439, SAE 4340, EN24
Mining machinery series 655M13, 826M40, 25CrMo
Wind power gear series 18CrNiMo7-6, 17CrNiMo6, 1.6582, 1.6587, SAE 8620
Wind power spindle series 34CrNiMo6, 817M40
Nitriding series 20MnCr5, 38CrMoAl, 31CrMoV9
Pressure vessel series 15CrMo, 13CrMo4-4
Metallurgical roll series 21CrMoV511, W1.7225, EN19, 709M40
Available Forged Steel Sizes
  • Forged Steel Round Bar: Φ85mm ~ 1200mm
  • Forged Square Steel Bar: 150×150 - 800×800mm
  • Forged Flat Blocks: (150mm-800mm) × (200mm-800mm)
  • Forged Shaft and Forged Rings: According to customer's drawing
Frequently Asked Questions
How long is your delivery time?
Generally 5-10 days if goods are in stock, or 15-20 days if not in stock, depending on quantity.
Do you provide samples? Is it free or extra?
Yes, we offer samples free of charge but customers pay the freight cost.
What is your MOQ?
Usually 5 tons. Smaller quantities may have higher pricing, while larger quantities receive better pricing.
How to buy your ideal products?
Provide your drawing for production, or we can design according to your requirements if you don't have a clear plan.
How to pay?
TT and L/C acceptable (TT preferred). 30% deposit before production, 70% balance before loading by TT.
How to install after the goods destination?
We provide installation instructions and videos. Technicians can be sent if necessary, with visa fees, air tickets, accommodation, and wages provided by buyers.
How to get an accurate quotation?
Provide product detail size & length, product quantities, and product material grade.
What other items from this supplier?
Angle line structural steel, H beam, I beam, Channel. Square, rectangular, round hollow section pipe. Steel plate, checker plate, corrugated sheet, steel coil. Flat, square, round bar. Screw, Stud bolt, nut, washer, flange and other related pipe kits.
