SAE1045 Cold Drawn Carbon Steel Bar with Polished Surface for High Strength Applications
SAE1045 Cold Drawn Carbon Steel Bar with Polished Surface for High Strength Applications
SAE1045 Cold Drawn Carbon Steel Bar with Polished Surface for High Strength Applications
SAE1045 Cold Drawn Carbon Steel Bar with Polished Surface for High Strength Applications
SAE1045 Cold Drawn Carbon Steel Bar with Polished Surface for High Strength Applications
SAE1045 Cold Drawn Carbon Steel Bar with Polished Surface for High Strength Applications
SAE1045 Cold Drawn Carbon Steel Bar with Polished Surface for High Strength Applications
SAE1045 Cold Drawn Carbon Steel Bar with Polished Surface for High Strength Applications
SAE1045 Cold Drawn Carbon Steel Bar with Polished Surface for High Strength Applications
SAE1045 Cold Drawn Carbon Steel Bar with Polished Surface for High Strength Applications
SAE1045 Cold Drawn Carbon Steel Bar with Polished Surface for High Strength Applications
SAE1045 Cold Drawn Carbon Steel Bar with Polished Surface for High Strength Applications
Specifications
MOQ :
1 Ton
Price :
US $690-1,150 / Ton
Model NO. :
SAE1045
Surface Treatment :
Polished
Alloy Type :
Non-alloy
Diameter Range :
OD 6-630mm
Carbon Content :
0.42-0.5
Silicon Content :
0.17-0.37
Manganese Content :
0.5-0.8
Chromium Content :
≤0.25
Phosphorus Content :
≤0.035
Sulfur Content :
≤0.035
Nickel Content :
≤0.3
Copper Content :
≤0.25
Tensile Strength :
600 N/mm2
Yield Strength :
355 N/mm2
Hardness :
229 HB
Description
SAE1045 Cold Drawn Carbon Steel Bar 45# Cold Drawn Steel Bar
Product Overview

AISI 1045 steel round bar is a high carbon steel under American standards, classified as a quenching and tempering steel with high strength properties. This alloy steel is available in various forms including hot rolled round bars, square bars, cold-drawn bars, and forged bars.

AISI 1045 round bar is extensively used for manufacturing moving parts requiring high strength, such as air compressor and pump plungers, rolled shafts, connecting rods, endless screws, gear racks, and dowels for heavy machinery. The material is typically delivered in quenching and tempering or normalizing states. After high-frequency quenching or shot peening, AISI 1045 round bar can be utilized to produce wear-resistant components including crank axles, machine tool shafts, and transmission shafts.

Cold Roll Steel Round Bar/Rod 1045 is commonly employed for industrial, machine, and tool applications. As a widely used low carbon steel alloy, it offers excellent strength, ductility, and machining ease. 1045 stock is available in full size and custom cut lengths.

Chemical Composition
Grade C Si Mn Cr P S Ni Cu
AISI 1045 0.42-0.5 0.17-0.37 0.5-0.8 ≤0.25 ≤0.035 ≤0.035 ≤0.3 ≤0.25
Mechanical Properties
Grade Delivery State T.S. N/mm² Min Y.S. N/mm² Min A,% Min Z,% Min Hardness, HB,max Forging ratio Grain Size (level) Nonmetal ratio
AISI 1045 Hot rolled, forged, or heat treatment 600 355 16 40 229 197 ≥ 4:1 ≥ 6 ≤ 2.0
Available Steel Grades
Steel Series Representative Steel Type
Carbon Steel seriesAISI 1020,1045,A36,S355JR,S355JO
Petroleum machinery seriesAISI4150,AISI4140,AISI4130,30CrMo,4145H
Tool mold series1.2714,5CrMnMo,5CrNiMoV,1.2738,1.2311,1.2312
Bearing series52100,GCr15,SUJ2
Marine series4140,42CrMo,SCM440,709M40
Car seriesSAE8620,20CrNiMo,SNCM220
Heavy-duty transmission series40CrNiMo,SNCM439,SAE4340,EN24
Mining machinery series655M13,826M40,25CrMo
Wind power gear series18CrNiMo7-6, 17CrNiMo6, 1.6582,1.6587,SAE8620
Wind power spindle series34CrNiMo6,817M40
Nitriding series20MnCr5,38CrMoAl,31CrMoV9
Pressure vessel series15CrMo,13CrMo4-4
Metallurgical roll series21CrMoV511,W1.7225,EN19,709M40
Forged Steel Dimensions
  • Forged Steel Round Bar: Φ85mm~1200mm
  • Forged Square Steel Bar: 150×150-800×800mm
  • Forged Flat Blocks: (150mm-800mm)×(200mm-800mm)
  • Forged Shaft and Forged Rings: According to Customer's drawing
Frequently Asked Questions
How long is your delivery time?
Generally 5-10 days if goods are in stock, or 15-20 days if not in stock, depending on quantity.
Do you provide samples? Is it free or extra?
Yes, we offer samples free of charge but freight costs are not included.
What is your MOQ?
Usually 5 tons. Smaller quantities may have slightly higher prices, while larger quantities receive lower pricing.
How to buy your ideal products?
Provide your drawing for production, or we can design according to your requirements if you don't have a clear plan.
How to pay?
TT and L/C are acceptable, with TT preferred. 30% deposit before production, 70% balance before loading by TT.
How to install after the goods destination?
We provide installation instructions and videos. Technicians can be sent if necessary, with visa fees, air tickets, accommodation, and wages covered by buyers.
How to get an accurate quotation?
Provide product detail size & length, product quantities, and product material grade.
What other items from this supplier?
Angle line structural steel, H beam, I beam, Channel. Square, rectangular, round hollow section pipe. Steel plate, checker plate, corrugated sheet, steel coil. Flat, square, round bar. Screw, Stud bolt, nut, washer, flange and other related pipe kits.
