JIS G3141 SPCC Cold Rolled Steel Coil CRC with 0.12-4mm Thickness and Slit Edge
JIS G3141 SPCC Cold Rolled Steel Coil CRC with 0.12-4mm Thickness and Slit Edge
JIS G3141 SPCC Cold Rolled Steel Coil CRC with 0.12-4mm Thickness and Slit Edge
JIS G3141 SPCC Cold Rolled Steel Coil CRC with 0.12-4mm Thickness and Slit Edge
JIS G3141 SPCC Cold Rolled Steel Coil CRC with 0.12-4mm Thickness and Slit Edge
JIS G3141 SPCC Cold Rolled Steel Coil CRC with 0.12-4mm Thickness and Slit Edge
JIS G3141 SPCC Cold Rolled Steel Coil CRC with 0.12-4mm Thickness and Slit Edge
JIS G3141 SPCC Cold Rolled Steel Coil CRC with 0.12-4mm Thickness and Slit Edge
JIS G3141 SPCC Cold Rolled Steel Coil CRC with 0.12-4mm Thickness and Slit Edge
JIS G3141 SPCC Cold Rolled Steel Coil CRC with 0.12-4mm Thickness and Slit Edge
JIS G3141 SPCC Cold Rolled Steel Coil CRC with 0.12-4mm Thickness and Slit Edge
JIS G3141 SPCC Cold Rolled Steel Coil CRC with 0.12-4mm Thickness and Slit Edge
Specifications
MOQ :
1 Ton
Price :
US $630-1,150 / Ton
Model NO. :
SPCC
Edge type :
Slit edge
Width range :
10-2000mm
Thickness range :
0.12-4mm
Coil ID :
508/610 mm
Coil weight :
3-10 tons
Production capacity :
1500 tons per month
Surface treatment :
Oil/dry/passivation/pickling
Carbon content :
≤0.12
Manganese content :
≤0.60
Phosphorus content :
≤0.045
Sulfur content :
≤0.045
Aluminum content :
≥0.020
Tensile strength :
270-410 MPa
Elongation :
≥28%
Description
JIS G3141 SPCC Cold Rolled Steel Coil CRC
Steel Strip Coil with thickness range of 0.12-4mm for industrial applications.
Product Overview
Cold-rolled steel sheet, abbreviated as cold-rolled plain carbon structural plate, is commonly known as cold plate. Manufactured from ordinary carbon structural hot-rolled steel strip, cold plate undergoes further cold rolling to achieve thicknesses under 4mm. The room temperature rolling process eliminates iron oxide formation, resulting in superior surface quality and precise dimensional accuracy. Combined with annealing treatment, cold-rolled steel offers enhanced mechanical and technological properties compared to hot-rolled steel sheets, making it the preferred choice in numerous applications, particularly in household appliance manufacturing.
Chemical Composition
Grade C Mn P S Alta
DC01, SPCC ≤0.12 ≤0.60 ≤0.045 ≤0.045 ≥0.020
DC02, SPCD ≤0.10 ≤0.45 ≤0.035 ≤0.035 ≥0.020
DC03, SPCE ≤0.08 ≤0.40 ≤0.030 ≤0.030 ≥0.020
DC04, SPCF ≤0.06 ≤0.35 ≤0.025 ≤0.025 ≥0.015
Mechanical Properties
Grade RCL (Mpa) RM (MPa) A80mm (%) R90 N90
DC01 140~280 270~410 ≥28
DC02 140~240 270~370 ≥34 ≥1.4
DC03 120~210 270~350 ≥38
Technical Specifications
Standards: AISI, ASTM, DIN, GB, JIS, BIS, EN
Materials: SPCC, SPCD, SPCE, ST12-15, DC01-06, Q195A-Q235A, Q195, Q235AF
Thickness: 0.11-2.0mm
Width: 20-1250mm
Normal Width: 750mm, 914mm, 1000mm, 1219mm, 1220mm, 1250mm
Length: Custom requirements or cut to sheet
Tolerance: Thickness +/-0.02mm, Width +/-0.02mm
Coil ID: 508/610 mm
Coil Weight: 3-10 tons
Production Capacity: 1500 tons per month
Surface Treatment: Oil/dry/passivation/pickling
Applications
Galvanized steel, PPGI, doors, household applications, manufacturing, shipping building, and various industrial sectors.
Company Information
Shandong Zhongcan Steel New Material Co., Ltd. is located in Taian City, Shandong Province. We welcome potential clients to visit our factory and explore our manufacturing capabilities.
Frequently Asked Questions
Available Sizes
Cold rolled steel coil: 0.12-2.0mm × Width × Coil
Cold rolled steel sheet: 0.12-2.0mm × Width × Length
Sample Availability
Yes, we provide free samples before order placement. We are confident you will be satisfied with our product quality.
Delivery Terms
EXW, FOB (Shanghai) or CIF to your discharge port.
Delivery Time
Color steel coil/sheet: Approximately 30 days for most sizes.
