1.5mm Thickness DC01 Grade Cold Rolled Steel Strip with Slit Edge for Industrial Applications
1.5mm Thickness DC01 Grade Cold Rolled Steel Strip with Slit Edge for Industrial Applications
1.5mm Thickness DC01 Grade Cold Rolled Steel Strip with Slit Edge for Industrial Applications
1.5mm Thickness DC01 Grade Cold Rolled Steel Strip with Slit Edge for Industrial Applications
1.5mm Thickness DC01 Grade Cold Rolled Steel Strip with Slit Edge for Industrial Applications
1.5mm Thickness DC01 Grade Cold Rolled Steel Strip with Slit Edge for Industrial Applications
1.5mm Thickness DC01 Grade Cold Rolled Steel Strip with Slit Edge for Industrial Applications
1.5mm Thickness DC01 Grade Cold Rolled Steel Strip with Slit Edge for Industrial Applications
1.5mm Thickness DC01 Grade Cold Rolled Steel Strip with Slit Edge for Industrial Applications
1.5mm Thickness DC01 Grade Cold Rolled Steel Strip with Slit Edge for Industrial Applications
1.5mm Thickness DC01 Grade Cold Rolled Steel Strip with Slit Edge for Industrial Applications
1.5mm Thickness DC01 Grade Cold Rolled Steel Strip with Slit Edge for Industrial Applications
Specifications
MOQ :
1 Ton
Price :
US $630-1,150 / Ton
Thickness :
1.5mm
Width Range :
10-2000mm
Material Grade :
DC01
Carbon Content :
≤0.12
Manganese Content :
≤0.60
Phosphorus Content :
≤0.045
Sulfur Content :
≤0.045
Aluminum Content :
≥0.020
Yield Strength :
140~280 Mpa
Tensile Strength :
270~410 Mpa
Elongation :
≥28%
Coil Inner Diameter :
508/610 mm
Coil Weight :
3-10 tons
Thickness Tolerance :
+/-0.02mm
Width Tolerance :
+/-0.02mm
Description
En10130 DC01 1.5mm Cold Rolled Steel Strip
Cold-rolled steel sheet, also known as cold-rolled plate or cold plate, is manufactured from hot-rolled carbon structural steel strips through further cold rolling to achieve thicknesses below 4mm. The cold rolling process at room temperature prevents iron oxide formation, resulting in superior surface quality and precise dimensional accuracy. Combined with annealing treatment, cold-rolled steel offers enhanced mechanical and technological properties compared to hot-rolled steel, making it ideal for various applications, particularly in household appliance manufacturing where it has largely replaced hot-rolled steel sheets.
Chemical Composition
Grade C Mn P S Alta
DC01, SPCC ≤0.12 ≤0.60 ≤0.045 ≤0.045 ≥0.020
DC02, SPCD ≤0.10 ≤0.45 ≤0.035 ≤0.035 ≥0.020
DC03, SPCE ≤0.08 ≤0.40 ≤0.030 ≤0.030 ≥0.020
DC04, SPCF ≤0.06 ≤0.35 ≤0.025 ≤0.025 ≥0.015
Mechanical Properties
Grade RCL (Mpa) RM (MPa) A80mm (%) R90 N90
DC01 140~280 270~410 ≥28
DC02 140~240 270~370 ≥34 ≥1.4
DC03 120~210 270~350 ≥38
Product Specifications
  • Standard: AISI, ASTM, DIN, GB, JIS, BIS, EN
  • Material: SPCC, SPCD, SPCE, ST12-15, DC01-06, Q195A-Q235A, Q195, Q235AF
  • Thickness: 0.11-2.0mm
  • Width: 20-1250mm
  • Normal Width: 750mm, 914mm, 1000mm, 1219mm, 1220mm, 1250mm
  • Length: According to customer requirements or cut to sheet
  • Tolerance: Thickness +/-0.02mm, Width +/-0.02mm
  • Coil ID: 508/610 mm
  • Coil Weight: 3-10 tons
  • Production Capacity: 1500 tons per month
  • Surface Treatment: Oil/dry/passivation/pickling
  • Application: Galvanized steel, PPGI, doors, household applications, manufacturing, shipping, building, and others
Company & Product Information
About Our Company:
Shandong Zhongcan Steel New Material Co., Ltd. is located in Taian City, Shandong Province. We welcome you to visit our factory if you are interested in our products.
Available Sizes:
Cold rolled steel coil: 0.12-2.0mm × Width × Coil
Cold rolled steel sheet: 0.12-2.0mm × Width × Length
Can we send samples before order?
Yes, we can send you samples for free, and we are confident you will like them.
Delivery Terms:
EXW, FOB (Shanghai) or CIF your discharge port.
Delivery Time:
10 days for standard products; approximately 30 days for color steel coil/sheet and specific sizes.
Product Images
1.5mm Thickness DC01 Grade Cold Rolled Steel Strip with Slit Edge for Industrial Applications 1.5mm Thickness DC01 Grade Cold Rolled Steel Strip with Slit Edge for Industrial Applications 1.5mm Thickness DC01 Grade Cold Rolled Steel Strip with Slit Edge for Industrial Applications 1.5mm Thickness DC01 Grade Cold Rolled Steel Strip with Slit Edge for Industrial Applications
