Specifications
Certification :
AISI, ASTM
MOQ :
50 kg
Price :
US $1.38-2.06 / kg
Model NO. :
430
Shape :
Flat
Technique :
Cold Rolled
Surface Treatment :
Polished
Specification :
1220*2440, 1500*3000, 1500*6000, 2000*6000mm
Thickness :
3-120mm
Tolerance :
+/-0.02mm
Width :
1500mm,1800mm,2000mm or as customized
Length :
6000mm or as customized
Finish :
2B, NO1, Hairline, No.4, BA, 8K mirror
Chemical Composition :
C ≤0.12, Mn ≤1.00, P ≤0.040, S ≤0.030, Cr 16.0-18.0
Yield Strength :
≥205 N/mm²
Tensile Strength :
≥420-450 N/mm²
Elongation :
≥22%
Hardness :
HRB ≤88-89
Description
430 Stainless Steel Sheet with PVC Film Protection
Stainless steel grade 430 is a non-hardenable steel containing straight chromium, belonging to the ferritic group of steels. This steel is known for its excellent corrosion resistance, formability, and practical mechanical properties. It demonstrates good resistance to nitric acid, making it suitable for various chemical applications.
Material Standards
AISI 430 | UNS S43000 | EN 1.4016
Key Features
  • Representative grade of ferritic stainless steel with magnetic properties
  • Low coefficient of thermal expansion with high thermal stability
  • Cost-effective composition without nickel and molybdenum content
  • Bright surface finish achieved through Bright Annealing or Mirror Finishing
Product Specifications
Grade 430 stainless steel sheet
Thickness 3-120mm
Tolerance ±0.02mm
Width 1500mm, 1800mm, 2000mm or customized
Length 6000mm or customized
Brand Name TISCO, LISCO, BAOSTEEL
Standard JIS, AISI, ASTM, GB, DIN, EN, etc.
Finish 2B, NO1, Hairline, No.4, BA, 8K mirror, etc.
Certification SGS
Ordering & Delivery
Packaging Standard exporting packing; seaworthy package
MOQ 1 Ton
Price Terms FOB, CFR, CIF, CNF
Delivery Time 15-20 working days after receiving deposit
Payment 30% T/T in advance + 70% balance; irrevocable L/C at sight
Insurance covers all risks and accepts third-party testing
Chemical Composition (Wt%)
Standard Grade C Mn P S Cr
ASTM 430 ≤0.12 ≤1.00 ≤0.040 ≤0.030 16.0-18.0
JIS SUS430 ≤0.12 ≤1.00 ≤0.040 ≤0.030 16.0-18.0
GB 10Cr17 ≤0.12 ≤1.00 ≤0.040 ≤0.030 16.0-18.0
Mechanical & Physical Properties
Standard Grade Y.S (N/mm²) T.S (N/mm²) EL (%) HRB Specific Heat (J/gºC) Modulus of Elasticity (KN/mm²)
JIS SUS430 ≥205 ≥420 ≥22 ≤88 - -
ASTM/GB 430 ≥205 ≥450 ≥22 ≤89 0.46 200
Applications
Ideal for kitchenware, household electrical appliances, and building decoration due to low cost, excellent corrosion resistance, and superior formability.
  • Architecture & Building: Surface panels, pillars, window frames, stair handrails
  • Kitchen Utensils: Washing machine drums, gas range stoves, plates, housewares, hollowware
  • Other Applications: Computer components, automotive trim
Available NO.1 Finish Stock
NO.1 Finish T×W×L W×L W×L
NO.1 Finish 3.0×1500×6000 1800×6000 2000×6000
NO.1 Finish 4.0×1500×6000 1800×6000 2000×6000
NO.1 Finish 5.0×1500×6000 1800×6000 2000×6000
NO.1 Finish 6.0×1500×6000 1800×6000 2000×6000
NO.1 Finish 8.0×1500×6000 1800×6000 2000×6000
NO.1 Finish 10×1500×6000 1800×6000 2000×6000
NO.1 Finish 12×1500×6000 1800×6000 2000×6000
NO.1 Finish 14×1500×6000 1800×6000 2000×6000
NO.1 Hot Rolling Production Line Requirements
Thickness (mm) Width (mm) Length (mm) Precision (mm) Straightness (mm) Length Error (mm) Trimedge Thickness (mm)
3.0-8.0 800-1600 1000-150000 ≤±1.5 ≤±1.0 ≤±1.5 ≤8.0
6.0-14.0 1000-2000 - - - - ≤14.0
8.0-18.0 1250-2000 - - - - ≤16.0
