Specifications
Certification :
AISI, ASTM
MOQ :
100 kg
Price :
US $2.35-3.5 / kg
Model Number :
444
Shape :
Flat
Technique :
Cold Rolled
Surface Treatment :
Bright
Specification :
1220*2440, 1500*3000, 1500*6000, 2000*6000mm
Production Capacity :
500000kgs
Carbon Content :
0.025 max
Chromium Content :
17.50-19.50
Molybdenum Content :
1.75-2.50
Density :
7.75 g/cm3
Electrical Resistivity :
57 microhm-cm
Thermal Conductivity :
26.8 W/m•K
Tensile Strength :
414 MPa min
Yield Strength :
276 MPa min
Elongation :
22% min
Description
Cold Rolled 444 Stainless Steel Sheet
AISI 444 Inox Sheet for Water Tank Applications
Product Overview
EN 1.4521 / AISI 444 grade stainless steel is a dual stabilized ferritic stainless steel containing 2% molybdenum. This grade offers excellent corrosion properties comparable to austenitic grades 4401/4404, with higher strength values due to molybdenum alloying.
Key Features
  • Excellent corrosion resistance comparable to 316 stainless steel
  • Superior resistance to chloride stress corrosion cracking
  • Excellent formability and deep drawability
  • Dual stabilization with titanium and niobium
  • Approved for drinking water applications by German (DVGW) and Swiss (SVGW) authorities
Applications
Food processing equipment, brewery and wine making equipment, hot-water tanks, heat-exchanger tubing, automotive components, solar water heaters, and drinking water systems.
Technical Specifications
Chemical Composition (Typical)
ElementContent (%)
Carbon0.025 max
Manganese1.00 max
Silicon0.60
Chromium17.50-19.50
Nickel1.00 max
Molybdenum1.75-2.50
Titanium + Columbium0.20 + 4x (C+N) min - 0.80 max
Phosphorus0.040 max
Sulfur0.030 max
IronBalance
Physical Properties
PropertyValue
Density0.28 lbs/in³ (7.75 g/cm³)
Electrical Resistivity22.50 microhm-in (57 microhm-cm)
Specific Heat0.102 BTU/lb·°F (0.427 kJ/kg·K)
Thermal Conductivity15.5 BTU/hr/ft²/ft/°F (26.8 W/m·K)
Thermal Expansion6.1 × 10⁻⁶ in/in/°F (11.0 µm/m·K)
Modulus of Elasticity29 × 10³ ksi (200 × 10³ MPa)
Magnetic PermeabilityMagnetic
Melting Range2700-2790°F (1482-1532°C)
Mechanical Properties (Annealed)
PropertyValue
Ultimate Tensile Strength60 KSI min (414 MPa min)
Yield Strength (0.2% offset)40 KSI min (276 MPa min)
Elongation22% min
HardnessRb 90 max
Available Forms
Coil - Strip, Foil, Ribbon | Wire - Profile, Round, Flat, Square
Surface Finishes
  • #1 - Hot rolled annealed and descaled
  • #2D - Dull finish for deep drawn parts
  • #2B - Smooth finish with brighter appearance
  • BA - Bright annealed cold rolled
  • CBA - Course bright annealed matte finish
  • 2BA - Smooth glossy finish for formed applications
  • Polished - Various grit finishes available
Not all finishes are available for all alloys - Contact sales for availability.
Processing Characteristics
Cold Forming: Excellent formability with superior deep drawing and spin forming capabilities. Limited stretch forming applications.
Welding: Good weldability with minimal heat input required. Austenitic fillers typically used.
Heat Treatment: Non-heat treatable alloy.
