TP304L Stainless Steel Seamless Tubing , ASTM A269 Industrial 2 inch round steel Pipe
TP304L Stainless Steel Seamless Tubing , ASTM A269 Industrial 2 inch round steel Pipe
TP304L Stainless Steel Seamless Tubing , ASTM A269 Industrial 2 inch round steel Pipe
TP304L Stainless Steel Seamless Tubing , ASTM A269 Industrial 2 inch round steel Pipe
TP304L Stainless Steel Seamless Tubing , ASTM A269 Industrial 2 inch round steel Pipe
TP304L Stainless Steel Seamless Tubing , ASTM A269 Industrial 2 inch round steel Pipe
TP304L Stainless Steel Seamless Tubing , ASTM A269 Industrial 2 inch round steel Pipe
TP304L Stainless Steel Seamless Tubing , ASTM A269 Industrial 2 inch round steel Pipe
Specifications
Brand Name :
SPEZILLA
Model Number :
304/304L, 316/316L
Certification :
ISO9001:2008
Place of Origin :
CHINA
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T or L/C
Supply Ability :
1000 TONS / MONTH
Delivery Time :
10 DAYS
Packaging Details :
PLY-WOODEN CASE / BUNDLE WITH PLASTIC CAP
Product Name :
Stainless Steel Seamless Tube
Standard :
ASTM A213/ASTM A269
Production :
Seamless, Welded, Welded & Drawn
Application :
Industry/Heat Exchanger
Steel Type :
304/304L, 316/316L
Size :
1/4'', 3/8'', 1/2'', 5/8'', 3/4'', 1''
Tube Testing :
100% Eddy Current
Tube Finish :
Annealed & Pickled, Bright Annealed
Shape :
Round
Package :
Wooden Case
Description

TP304L Stainless Steel Seamless Tubing , ASTM A269 Industrial 2 inch round steel Pipe

Description:

Spezilla manufacture standard sizes of seamless and welded stainless instrumentation tubing. Our stainless steel instrumentation tubing primarily consist of the austenitic grades of 304, 304L, 316 and 316L, in a size range from 1/4” to 1/2” outside diameters in straight lengths and coils, where applicable. Stainless steel instrumentation tubing is stocked in the annealed and pickled, bright annealed, mill finish and polished conditions. These are the four most popular austenitic grades of stainless steel which provide excellent overall corrosion resistance.

Tubing Grade: 316/316L

Tube OD sizes (Fractional): 1/8, 1/4, 1/2, 5/8, 3/4, 1 in.

Tube OD sizes (Metric): 6, 8, 10, 12, 16, 18, 20, 25 mm

Wall Thickness (Fractional): 0.028, 0.035, 0.049, 0.065, 0.083, 0.095, and 0.109 in.

Wall Thickness (Metric): 1.0, 1.5, 2.0, and 2.5 mm

Applications:

Spezilla's stainless steel instrumentation tubing are sold to a wide range of industries/markets, due to their overall corrosion resistance and good machinability:

  • Power Generation
  • Automotive
  • Chemical and Petrochemical
  • Oil and gas platforms:
  • Process instrumentation and sensing
  • Chemical inhibition
  • Impulse lines
  • Hydraulic application

Specification:

Stainless Steel Instrumentation Tubing Chemical Requirements (wt%)
Elements TP304 TP304L TP316 TP316L
C Max. 0.08 0.030 0.08 0.030
Mn Max. 2.00 2.00 2.00 2.00
P Max. 0.045 0.045 0.045 0.045
S Max. 0.030 0.030 0.030 0.030
Si Max. 1.00 1.00 1.00 1.00
Cr 18.0-20.0 18.0-20.0 16.0-18.0 16.0-18.0
Ni 8.0-11.0 8.0-12.0 10.0-14.0 10.0-14.0
Mo - - 2.0-3.0 2.0-3.0
N - - - -
Cu - - - -
Other - - - -

Stainless Steel Instrumentation Tubing Dimensional Tolerances ASTM A269
Size OD Outside Diameter(MM) Length(MM) Wall (MM)
Up to 1/2''(13) +/-0.005 (+/-0.13)

+1/8''(3.2)/-0

 +/-15.0%
1/2'' to 11/2'' (13 to 38), excl +/-0.005 (+/-0.13) +1/8''(3.2)/-0 +/-10.0%
11/2'' to 31/2'' (38 to 89), excl +/-0.010 (+/-0.25) +3/16''(4.8)/-0 +/-10.0%
31/2'' to 51/2''(89 to 140), excl +/-0.015 (+/-0.38) +3/16''(4.8)/-0 +/-10.0%
51/2'' to 8'' (140 to 203), excl +/-0.030 (+/-0.76) +3/16''(4.8)/-0 +/-10.0%
8'' to 12'' (203 to 305), excl +/-0.010 (+/-1.01) +3/16''(4.8)/-0 +/-10.0%
12'' to 14'' (305 to 356), excl +/-0.050 (+/-1.26) +3/16''(4.8)/-0 +/-10.0%


TP304L Stainless Steel Seamless Tubing , ASTM A269 Industrial 2 inch round steel Pipe
