Specifications
Brand Name :
SPEZILLA
Model Number :
SP-SMLS
Certification :
ISO9001:2015
Place of Origin :
CHINA
MOQ :
1PC
Price :
NEGOCIATION
Payment Terms :
L/C, T/T
Supply Ability :
100TONS/MONTH
Delivery Time :
7 DAYS
Packaging Details :
WOODEND BOXED
Product Name :
Stainless Stee Hydraulic Tubing
Type :
SMLS
Production :
Cold Drawn
Finish :
Bright Annealed
Size :
1/4'' - 1-1/2''
Materials :
AISI 316L, 1.4404
Inspection :
EN10204 3.1
Certificate :
ISO9001:2015
Description

TP304/304L Stainless Steel Seamless Tubing , ASTM A269 Ininstrumentation Tubing, OD Polished

Description:

Spezilla manufacture standard sizes of seamless and welded stainless instrumentation tubing. Our stainless steel instrumentation tubing primarily consist of the austenitic grades of 304, 304L, 316 and 316L, in a size range from 1/4” to 1/2” outside diameters in straight lengths and coils, where applicable. Stainless steel instrumentation tubing is stocked in the annealed and pickled, bright annealed, mill finish and polished conditions. These are the four most popular austenitic grades of stainless steel which provide excellent overall corrosion resistance.

Tubing Grade: 316/316L

Tube OD sizes (Fractional): 1/8, 1/4, 1/2, 5/8, 3/4, 1 in.

Tube OD sizes (Metric): 6, 8, 10, 12, 16, 18, 20, 25 mm

Wall Thickness (Fractional): 0.028, 0.035, 0.049, 0.065, 0.083, 0.095, and 0.109 in.

Wall Thickness (Metric): 1.0, 1.5, 2.0, and 2.5 mm

Applications:

Spezilla's stainless steel instrumentation tubing are sold to a wide range of industries/markets, due to their overall corrosion resistance and good machinability:

1. Power Generation

2. Automotive

3. Chemical and Petrochemical

4. Oil and gas platforms:

Process instrumentation and sensing

Chemical inhibition

Impulse lines

Hydraulic application

Specification:

Stainless Steel Instrumentation Tubing Chemical Requirements (wt%)
Elements TP304 TP304L TP316 TP316L
C Max. 0.08 0.030 0.08 0.030
Mn Max. 2.00 2.00 2.00 2.00
P Max. 0.045 0.045 0.045 0.045
S Max. 0.030 0.030 0.030 0.030
Si Max. 1.00 1.00 1.00 1.00
Cr 18.0-20.0 18.0-20.0 16.0-18.0 16.0-18.0
Ni 8.0-11.0 8.0-12.0 10.0-14.0 10.0-14.0
Mo - - 2.0-3.0 2.0-3.0
N - - - -
Cu - - - -
Other - - - -

Stainless Steel Instrumentation Tubing Dimensional Tolerances ASTM A269
Size OD Outside Diameter(MM) Length(MM) Wall (MM)
Up to 1/2''(13) +/-0.005 (+/-0.13) +1/8''(3.2)/-0 +/-15.0%
1/2'' to 11/2'' (13 to 38), excl +/-0.005 (+/-0.13) +1/8''(3.2)/-0 +/-10.0%
11/2'' to 31/2'' (38 to 89), excl +/-0.010 (+/-0.25) +3/16''(4.8)/-0 +/-10.0%
31/2'' to 51/2''(89 to 140), excl +/-0.015 (+/-0.38) +3/16''(4.8)/-0 +/-10.0%
51/2'' to 8'' (140 to 203), excl +/-0.030 (+/-0.76) +3/16''(4.8)/-0 +/-10.0%
8'' to 12'' (203 to 305), excl +/-0.010 (+/-1.01) +3/16''(4.8)/-0 +/-10.0%
12'' to 14'' (305 to 356), excl +/-0.050 (+/-1.26) +3/16''(4.8)/-0 +/-10.0%
