7X7 Balustrade Mesh Infill 304L 316L Banister Guard Netting Flexible Metal
7X7 Balustrade Mesh Infill 304L 316L Banister Guard Netting Flexible Metal
7X7 Balustrade Mesh Infill 304L 316L Banister Guard Netting Flexible Metal
7X7 Balustrade Mesh Infill 304L 316L Banister Guard Netting Flexible Metal
7X7 Balustrade Mesh Infill 304L 316L Banister Guard Netting Flexible Metal
7X7 Balustrade Mesh Infill 304L 316L Banister Guard Netting Flexible Metal
7X7 Balustrade Mesh Infill 304L 316L Banister Guard Netting Flexible Metal
7X7 Balustrade Mesh Infill 304L 316L Banister Guard Netting Flexible Metal
Specifications
Brand Name :
Jianping
Model Number :
JP-2060F
Certification :
CE , SGS
Place of Origin :
China
MOQ :
10 Sqm
Price :
USD 5-30/m2
Payment Terms :
T/T, Western Union,PayPal
Supply Ability :
9000m2/week
Delivery Time :
5-8 Work Days
Packaging Details :
Package film for each piece,Several pieces packed in 1 carton
Product Name :
Flexible Metal Mesh Netting Balustrade Infiller for Marinasl/Balustrade Mesh Infill
Material :
Stainless Steel Wire, 304, 316, AISI 304/316/304L/316L
Rope Constructions :
7 X 7,7×19
Mesh Angle :
60 Degree
Wire Diameter :
1.2 Mm 1.5mm 2.0mm 2.5mm 3.0mm 4.0mm
Size Of Hole :
25*25mm-300*300mm
Panel Size :
Customized In Width And Length
Finished :
Ultrasonic Bath , Black Oxide
Mesh Shape :
Rhombus , Diamond
Mesh Type :
Ferruled Or Knotted
High Light: :
Stainless Steel Rope Mesh, Deck Railing
Application :
Zoological Enclosures , Blustrade Infill , Facade Cladding
Description

Flexible Metal Mesh Netting Balustrade Infiller for Marinasl/Balustrade Mesh Infill

Flexible Metal Mesh Netting Balustrade Infiller for Marinasl/Balustrade Mesh Infill Description :

Stainless steel wire rope mesh (also called cable mesh) made form high quality stainless steel wire rope, with the features of extremely anti-corrosion and resistant to UV rays, has a long lifespan in the harsh environments. And its largest benefit is particular resilience and flexibility. Our rope mesh may in knotted, ferrule type, woven square, or square mesh with cruciate/cross clamps. They are all favored by fashion architects.

Stainless steel rope net is a net-like product processed by stainless steel rope according to certain methods and procedures. The common ones are mainly stainless steel buckle rope net and stainless steel braided rope net. The stainless steel buckle rope net is extruded and woven by stainless steel wire rope and stainless steel buckle.The steel buckle is mainly made of stainless steel buckle, and there are also aluminum buckles and copper buckles for customers to choose from.The stainless steel rope mesh woven net is formed by cross-weaving with a plurality of steel wire ropes, and the net is durable and unbreakable, and the bearing capacity is large.

7X7 Balustrade Mesh Infill 304L 316L Banister Guard Netting Flexible Metal
Cable diameter
Mesh opening size
Nominal break
inch
mm
inch
mm
lbs.
1/8
3.2
4x4
102x102
1600
1/8
3.2
3x3
76x76
1600
1/8
3.2
2x2
51x51
1600
3/32
2.4
4x4
102x102
920
3/32
2.4
3x3
76x76
920
3/32
2.4
2x2
51x51
920
5/64
2.0
3x3
76x76
676
5/64
2.0
2x2
51x51
676
5/64
2.0
1-1/2x 1-1/2
38x38
676
1/16
1.6
3x3
76x76
480
1/16
1.6
2x2
51x51
480
1/16
1.6
1-1/2x 1-1/2
38x38
480
1/16
1.6
1x1
25.4x25.4
480
3/64
1.2
1-1/2x 1-1/2
38x38
270
3/64
1.2
1x1
25.4x25.4
270
3/64
1.2
4/5x4/5
20x20
270

Flexible Metal Mesh Netting Balustrade Infiller for Marinasl/Balustrade Mesh Infill

Specification of Flexible Metal Mesh Netting Balustrade Infiller for Marinasl/Balustrade Mesh Infill:
Flexible Metal Mesh Netting Balustrade Infiller for Marinasl/Balustrade Mesh Infill
Product Name

Flexible Metal Mesh Netting Balustrade Infiller for Marinasl/Balustrade Mesh Infill
Raw Material Stainless Steel 304 316, Galvanized Wire
Type Ferrule Type or Knotted Type
Specification Rope, 7x7 or 7x19
Mesh, 30mm to 200mm
Wire diameter, 1.0 to 4.0mm
Feature

1. high quality material

2. uniform mesh

3. standard size

4. long uselife

5. strong tensile

6. easy install
Application

1.Steel Mesh Balustrade - bridge, stair, balcony, path

2.Cable Mesh - Excellent Solution to Safety

3.Safety Net - Structural Measure to Prevent Suicide

4.Helipad Safety Net - Modular Heliport Webbing

5.Cable Zoo Mesh - Solution to Enclosing Most Animals

6.Aviary Netting - Lightweight, Durable and Long Lasting

7.Green Facade - Cable System for Most Climbing Plants
Packing The rope mesh will be rolled and packed into the P.P. woven bags or wooden crates.

7X7 Balustrade Mesh Infill 304L 316L Banister Guard Netting Flexible Metal

Packing & Delivery of Stainless Steel Wire Rope Mesh/Balustrades Mesh
1. The set of paper tube.
2. Outside waterproof paper (kraft paper) + bubble pad.
3. Finally in a wooden case or pallet.
4. Also we can as per your requirements.
