Specifications
MOQ :
Negotiable
Material :
Steel
Load Type :
Compression
Production Process :
Hot Roll
Shape :
Flat
Specification :
SUS 302
Diameter Range :
8mm to 200mm
Temperature Range :
-40°C to 200°C
Pressure Resistance :
up to 3000 psi
Salt Spray Resistance :
500 hours
Material Options :
65Mn, 60Si2MnA, SUS304, SUS316
Surface Treatment :
Phosphating
Operational Lifespan :
30% extended
Spring Type :
Single-layer closed wave
Elasticity :
High-performance
Impact Resistance :
Superior
Spring Stiffness :
Low
Axial Preload :
Reliable
Deformation Control :
Controlled
Load Capacity :
Minimal
Fatigue Resistance :
Excellent
Place of Origin :
Sihong, China
Brand Name :
Sunzo
Certification :
CE/IATF16949/45001/14001/9001
Price :
Negotiable
Packaging Details :
Carton
Delivery Time :
Negotiable
Payment Terms :
Negotiable
Description
High-Quality Waved Spring with Phosphating Finish
Premium Elastic Solution for Hydraulic Seal Systems

Our waved spring (wave spring) is a high-performance elastic element engineered to deliver exceptional elasticity and superior impact resistance in demanding industrial environments.

Key Features
  • Precision-engineered wave pattern with alternating peaks and valleys
  • Optimized for minimal load, controlled deformation, and low spring stiffness
  • Advanced phosphating surface treatment for enhanced corrosion resistance
  • Withstands up to 500 hours of salt spray testing
  • Extends operational lifespan by 30% compared to untreated alternatives
  • Operational temperature range: -40°C to 200°C
  • Handles high-pressure conditions up to 3000 psi
Available Materials
65Mn
High carbon spring steel for optimal flexibility
60Si2MnA
Alloy steel with excellent fatigue resistance
SUS304
Food-grade stainless steel for corrosion-prone environments
SUS316
Marine-grade stainless steel for extreme chemical resistance
Product Specifications
  • Standard single-layer closed wave springs
  • Diameter range: 8mm to 200mm
  • Fully customizable non-standard designs available
  • Rigorous quality control including load testing and dimensional inspection
  • Complies with ISO 9001 and AS9100 standards
Applications

Ideal for critical hydraulic seal applications in automotive, industrial machinery, and oil & gas sectors.
