Specifications
MOQ :
100 units
Model NO. :
sunzo
Function :
Pressed, Phonation, Drive, Restoration, Measurement
Material :
Steel
Load Type :
Compression
Production Process :
Fine Punching
Shape :
Flat
Specification :
50CrVA
Tensile Strength :
1,400 MPa
Impact Resistance :
500G dynamic loads
Diameter Range :
5mm-500mm
Material Options :
65Mn, 60Si2MnA, SUS304, SUS316, Inconel718
Fatigue Resistance :
10⁶+ load cycles
High-Temperature Stability :
up to 650°C
Salt Spray Resistance :
1,000+ hours
Dimensional Accuracy :
±0.01mm
Lead Time :
7-15 days
Surface Treatments :
Dacromet coating, Phosphating, Black oxide
Material Certification :
ISO 9001, AS9100
Dynamic Load Capacity :
500G
Place of Origin :
Sihong, China
Brand Name :
Sunzo
Certification :
CE/IATF16949/45001/14001/9001
Price :
Negotiable
Packaging Details :
Carton
Delivery Time :
Negotiable
Payment Terms :
Negotiable
Description
Wholesale Waved Spring Solutions - SUNZO High-Quality Wave Springs with Competitive Pricing for Global Industrial Partners
Premium Wave Spring Solutions

SUNZO is a leading manufacturer delivering premium-quality waved springs (also termed wave springs) at highly competitive wholesale prices, backed by 15+ years of engineering expertise. Our waved springs are precision-engineered elastic components featuring meticulously formed peaks and valleys on a single metal ring, delivering exceptional performance for industrial applications.

Technical Specifications
  • Exceptional Elasticity: Tensile strength up to 1,400 MPa
  • Superior Impact Resistance: Withstands 500G dynamic loads
  • Extensive Size Range: Standard single-layer closed wave springs from 5mm to 500mm diameters
  • Fatigue Resistance: Engineered for 10⁶+ load cycles
Material Selection
  • 65Mn Spring Steel: Excellent fatigue resistance
  • 60Si2MnA: Superior flexibility for dynamic applications
  • SUS304/SUS316 Stainless Steel: Corrosion resistance in harsh environments
  • Inconel718: High-temperature stability up to 650°C
Surface Treatments

Enhanced durability through dacromet coating (1,000+ hours salt spray resistance), phosphating, and black oxide finishing to meet rigorous industry requirements.

Wholesale Partnership Benefits
  • Volume-based pricing discounts
  • Flexible MOQ options starting from 100 units
  • Rapid lead times: 7-15 days for standard products
  • End-to-end technical support including design consultation and FEA simulation
  • Strict quality control complying with ISO 9001 and AS9100 standards
Applications

Our waved springs serve diverse sectors including aerospace, precision machinery, hydraulic systems, automotive transmissions, and high-end electric motors.
