High Elasticity Waved Spring with Dimensional Stability and 50CrVA Material for Precision Machinery
High Elasticity Waved Spring with Dimensional Stability and 50CrVA Material for Precision Machinery
High Elasticity Waved Spring with Dimensional Stability and 50CrVA Material for Precision Machinery
High Elasticity Waved Spring with Dimensional Stability and 50CrVA Material for Precision Machinery
High Elasticity Waved Spring with Dimensional Stability and 50CrVA Material for Precision Machinery
High Elasticity Waved Spring with Dimensional Stability and 50CrVA Material for Precision Machinery
Specifications
MOQ :
Negotiable
Material :
Steel
Load Type :
Compression
Production Process :
Fine Punching
Shape :
Flat
Tensile Strength :
1,300 MPa
Impact Resistance :
300G dynamic loads
Load Capacity :
5N to 300N
Deformation Tolerance :
≤0.02mm
Space Savings :
40%
Diameter Range :
5mm-400mm
Fatigue Resistance :
10⁶ load cycles
High-Temperature Stability :
300°C
Salt Spray Resistance :
500+ hours
Dimensional Accuracy :
±0.01mm
Hardness :
HRC 45-50
Spring Stiffness :
Low
Material Grade :
50CrVA
Dynamic Load Capacity :
300G
Axial Preload :
Stable
Surface Treatment :
Phosphating, Electroless Nickel Plating
Place of Origin :
Sihong, China
Brand Name :
Sunzo
Certification :
CE/IATF16949/45001/14001/9001
Price :
Negotiable
Packaging Details :
Carton
Delivery Time :
Negotiable
Payment Terms :
Negotiable
Description
Waved Spring Application in Precision Machinery: High Elasticity & Stability for Critical Component Performance
Product Overview

Our waved spring is engineered for precision machinery applications requiring exceptional elasticity, dimensional stability, and reliable performance in micro-tolerance environments. This precision-formed metal ring with alternating peaks and valleys delivers superior performance in high-precision mechanical systems.

Key Performance Features
  • Superior elasticity with tensile strength up to 1,300 MPa
  • Exceptional impact resistance, withstanding 300G dynamic loads
  • Minimal deformation with ≤0.02mm tolerance
  • Compact design offering up to 40% space savings compared to conventional coil springs
  • Stable axial preload for maintaining component alignment and vibration reduction
  • Optimized for small load capacities (5N to 300N) with low spring stiffness
Applications

Ideal for precision machinery including CNC machine tool spindles, semiconductor wafer handling equipment, medical imaging devices, and optical instrument mechanisms.

Product Specifications
Type Standard single-layer closed waved springs
Diameter Range 5mm - 400mm
Material Options 1074 high-carbon steel, 65Mn spring steel, SUS302 stainless steel, 50CrVA alloy steel
Temperature Range Up to 300°C (with 50CrVA alloy steel)
Fatigue Resistance Exceeding 10⁶ load cycles
Surface Treatments
  • Plain oiled for general-purpose lubrication
  • Phosphating providing 500+ hours of salt spray resistance
  • Electroless nickel plating for enhanced wear resistance
Quality Assurance

Each spring undergoes rigorous testing including load-deflection curve validation, dimensional accuracy checks (±0.01mm), and hardness testing (HRC 45-50). All products comply with ISO 9001 standards to ensure seamless integration into precision machinery systems.

Product Image
