Specifications
Brand Name :
Shinhom
Model Number :
RF5S-0901
Certification :
RoHs,iso9001
Place of Origin :
China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
1000000/MONTH
Delivery Time :
4~8 Weeks
Packaging Details :
Carton
Frequency :
1-1500MHz
Characteristic Impedance :
75Ω
Type :
RF
Operating temperature :
-40℃ to +85℃
Storage temperature range :
-55℃ to +100℃
Description

9dB Directional Coupler,SMD RF Balun transformer,5 - 1500MHz,75 Ohm Characteristic Impedance

Features:

  • RoHS Compliant and Pb free
  • Surface mount and available in tape and reel
  • 260℃ reflow compatible
  • 75Ω Characteristic Impedance
  • Frequency: 1-1500MHz
  • Operating temperature: -40℃ to 85℃
  • Storage temperature: -55℃ to 100℃

Applications:

  • For catv
  • For broadband and wireless communications

ELECTRONICAL SPECIFICATIONS(25℃,Z=75Ω)

Parameter Test Conditions Units Min Typ Max
Main line Loss 5-1500MHz dB － 1.6 2.0
Coupling 5-1500MHz dB － 9.0 ±0.6
Input Return Loss 5-1500MHz dB 16.0 25.0 －
Output Return Loss 5-1500MHz dB 20.0 25.0 －
Coupling return loss 5-1500MHz dB 16.0 20.0 －
Isolation 5-1500MHz dB 18.0 22.0 －
