Specifications
warranty :
1 Year
customized support :
OEM, ODM
Place of Origin :
Guangdong, China
Brand Name :
3nh
Model Number :
HG60
Measure Angle :
60
Measurement Range :
60:0~300gu
Division Value :
0.1gu
Storage :
Basic Mode: 1000
Measuring Time :
0.5s
Description

3nh 60 Degree Single Angle Gloss Meter Car Paint Coating Glossmeter HG60

Product Description

HG60 gloss meter features with 60° angle, manufactured according to ISO2813 and GB/T 9754. It is also compatible with international standards of ASTM D523, ASTM D2457. HG268 conforms to JJG696 first class gloss meter working requirement, corresponding with CIE 1931(2°) under CIE C light source.

HG60 gloss meter is widely used to test glossiness in these industries, such as automobile, paint, ink, stoving varnish, coating, wood products; marble, granite, vitrified polished tile, pottery brick and porcelain; plastic, paper; hardware industries, etc.

Advantages

3nh 60 Degree Single Angle Gloss Meter Car Paint Coating Glossmeter HG60

Product Parameters

Model:

HG60

Measuring Angle

60°
Comply with standard ISO 2813, GB/T 9754, ASTM D 523, ASTM D 2457

Measuring Area (mm)

9x15

Measuring Range

0~300GU

Division Value

0.1GU

Measurement Range

Repeatability

Reproducibility

0-10GU 10-100GU 100-300GU
± 0.1GU ± 0.2GU ± 0.2%GU
± 0.2GU ± 0.5GU ± 0.5%GU

Measurement Standard

Conform with JJG696 first class glossmeter working requirement

Chromaticity Corresponding

Corresponding with CIE 1931(2°) under CIE C light source

Errors

±1.5 , ± 1.5%

Measuring Time

0.5s

Dimension

L*W*H : 160mm*75mm*90mm

Weight

350g

Language

Chinese/English

Battery

3.7V,3200mAh Li-ion Battery ,>10000 times(within 8 hours)

Display

TFT 3.5 inch

Interface

USB/RS-232

Storage

Basic mode: 1000

Software

GQC6 Quality Control Software with QC report printing functions and more extended functions.

Operation Temperature

0~40ºC(32~104°F)

Storage Temperature

-20~50ºC(-4~122°F)

Humidity

<85% relative humidity, no condensation

Standard Accessories

Power Adapter, USB cable, User Manual, GQC6 software CD (except HG60S), Calibration Plate

Optional Accessories

Miniature Printer

Note

The specifications are subject to change without notice.
Detailed Images

3nh 60 Degree Single Angle Gloss Meter Car Paint Coating Glossmeter HG603nh 60 Degree Single Angle Gloss Meter Car Paint Coating Glossmeter HG603nh 60 Degree Single Angle Gloss Meter Car Paint Coating Glossmeter HG60

Company Information

3nh 60 Degree Single Angle Gloss Meter Car Paint Coating Glossmeter HG60

FAQ

1. Which brand can 3nh spectrophotometer compare with in the world?
Answer: 3nh instruments can be used to compare with famous brands like Xrite, Minolta, BYK, Datacolor and Hunterlab.

2. Are you a trader or a manufacturer?
Answer: We 3nh is a professional manufacturer from China for 26 years. We research and develop, design and produce, market and sell color measuring instruments and gloss meters, color light box etc.

3. What's your main market?
Answer: We sell to the global market.

4. How long is your delivery time?
Answer: Generally it is 1-3 working days after the payment confirmed.

5. What is your payment terms?
Answer: The payment term is 100% T/T in advance.

6. What's your minimum order quantity (MOQ)?
Answer: Our MOQ is 1 set. If you order more than 3 sets, we can provide discount.

7. Do you support OEM and ODM service?
Answer: Yes, we support. Our MOQ for OEM and ODM service is 5 pcs for one model.

8. What about the warranty?
Answer: We offer 12 months warranaty for the instrument except consumables, and we offer the lifespan maintenenace for all goods.
