Specifications
Brand Name :
JINSP
Model Number :
PR100
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
100PCS/ 60-80 WORKING DAYS
Delivery Time :
60-80 WORKING DAYS
Packaging Details :
International Shipping Package
Flow Cell Compatibility :
Compatible with the FC100/FC200 flow cell
Compact and Lightweight :
Suitable for routine measurements of liquids and solids in conjunction with a sample chamber
Excitation Wavelengths :
532 nm, 785 nm, and 1064 nm
Temperature Range :
0 ~ 100 ºC
Outer Diameter :
10 Mm
Accepted Payment Methods :
T/T, Paypal, Western Union, L/C, etc.
Description

Customizing Raman Probe for Raman Systems Analysis

Compatible testing accessories for liquid online Raman analyzers and benchtop Raman spectrometers.

Product table list and parameters:

/ PR100 PR200 PR201 PR202 PR300
/ Optical Probe LAB Immersion Probe LAB Immersion Probe LAB Immersion Probe Industrial Immersion Probe
Probe Tube Material 304 stainless
steel		 C276 alloy, 304 stainless steel, 316L stainless steel, Monel alloy, or TA2 optional 316L stainless steel, resistant to SIP/CIP
sterilization		 C276 alloy, 304 stainless steel, 316L stainless steel, Monel alloy, or TA2 optional
Outer Diameter 10mm 10mm 16mm 12mm 60mm
Support customizing
Probe Tube Length 80mm 350 mm
Support customizing from 100 mm ~ 350 mm		 270 mm
Support customizing from 100 mm ~ 1000 mm		 120 mm
Support customizing from 120mm ~ 320 mm		 1.9 m
Support customizing from 1 m ~ 3 m
Spectral Range 200 ~ 3900 cm-1 (532 nm or 785 nm excitation wavelength)
230 ~ 3100 cm-1 (1064 nm excitation wavelength)
Sample Type Any sample type L (clear liquid) or S (opaque or turbid liquid) or C (slurries or semi-solids)
Fiber Optic Cable 1.3 m PVC jacketed as standard, 3 m or 5 m length are optional 5 m as standard ,10 m, 50 m or 100 m length are optional; PVC jacket as standard, TPU or silica gel jacket are optional 50 m
Support customizing
Temperature Range 0ºC ~ 100 ºC -40ºC ~ 200 ºC -40 ºC ~ 150 ºC -30 ºC ~ 200 ºC -60 ºC ~ 200 ºC
Maximum Pressure ambient condition 30 MPa 30 MPa 1 MPa 30 MPa
Corrosion Resistance Not resistant to corrosive liquid Resistant to strong acid/alkali, hydrofluoric acid (HF), and organic solution Resistant to strong acid/alkali, hydrofluoric acid (HF), and organic solution pH range: 1-14 Resistant to strong acid/alkali, hydrofluoric acid (HF), and organic
solution
Optical Fiber
Configuration		 100 μm excitation fiber, 200 μm collection fiber, N.A. 0.22
Filter Efficiency OD6, customizing is available
Connection Interface FC and SMA

Technical Highlights:

  • High collection efficiency: special optical design
  • Withstands high and low temperatures, high-pressure, harsh and extreme reaction conditions
  • Flexible customization: The interface, length, and material can be customized


Applications:

Supporting three laser wavelengths (532 nm, 785 nm, 1064 nm), the PR100 Raman probe is optimized for laboratory-based offline detection of liquids and solids in standard sample chambers. It also enables microscopic Raman analysis when used with a microscope. For dynamic applications, it can be linked to flow cells or side-view reactors, providing real-time insights into chemical processes.

Industrial Measurement 10Mm Raman Probe For Continuous Flow Reaction Systems

The PR200/PR201/PR202 probe family delivers precise in-situ monitoring for small-scale chemical reactions. These immersion units install directly into reaction vessels, with an advanced version specifically engineered to handle suspended solutions. Various material options provide exceptional performance under demanding conditions. The series includes models with different interface sizes: compact PR200 and medium-sized PR201. Particularly noteworthy is the PR202, designed for bio-fermentation monitoring with its high-temperature sterilizable, detachable probe assembly featuring a PG13.5 interface.

The PR300 series represents a reliable solution for industrial process monitoring, featuring exceptional resistance to extreme thermal and mechanical stresses. Its innovative design preserves optical system functionality while withstanding corrosive media. The flanged mounting system ensures stable installation in reaction kettles, with multiple sizing options available to match different vessel specifications and monitoring requirements.

Industrial Measurement 10Mm Raman Probe For Continuous Flow Reaction Systems

Company Introduction:

JINSP Company Limited has won the National Science and Technology Commission's Scientific and Technological Achievement Appraisal Certificate and the China Patent Excellence Award, and related products have been obtained has won authoritative awards such as the Geneva International Invention Award, the Beijing New Technology and New Product Certificate, and the "Innovation Achievement Award" of the Zhu Liangyi Analytical Instrument Innovation Award.

In addition, JINSP participated in the drafting of several national and international standards, including participating in the drafting of an international standard as the only participating unit in China IEC 63085 International Standard: System of spectral identification of liquids in transparent or semitransparent containers; Drafting of two national standards: GB/T 41086-2021 "General Technical Requirements for Safety Inspection Equipment for Hazardous Chemicals Based on Raman Spectroscopy", GB/T 40219-2021 "General Specification for Raman Spectrometer".

FAQ:

Q: What is the minimum order quantity for the JINSP Raman Probe ?

A: The minimum order quantity for the JINSP Raman Probe is 1PC.

Q: What is the price of the JINSP Raman Probe?

A: The price of the JINSP Raman Probe is negotiable.

Q: What payment terms are accepted for the JINSP Raman Probe ?

A: The accepted payment terms for the JINSP are T/T and Western Union.

Q: What is the delivery time for the JINSP Raman Probe?

A: The delivery time for the JINSP Raman Probe is 40-70 working days.

Q: Where is the JINSP Raman Probe manufactured?

A: All Raman Probe is designed and manufactured in China.
