Raspberry Cranberry Sorter IQF Fruit Sorting Equipment Automatic
Raspberry Cranberry Sorter IQF Fruit Sorting Equipment Automatic
Specifications
Brand Name :
PHOENIX
Model Number :
HDF AI-RGB Sorter
Place of Origin :
Hefei
MOQ :
1
Price :
Price Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Delivery Time :
5-8 work days
Model :
HDF2
Belt Width (mm) :
600
Air Nozzle :
256
Air Pressure (mpa) :
0.6-0.8
Description
HDF AI-RGB Sorter AI Powered And Tailored Design For IQF Vegetables And Fruit Sorting; Engineered For High-pressure Washing And Sterilization
Technical Features
  • Tailored Sorting Solution for IQF Vegetables and Fruit
  • Compact dual-belt sorting system with quick-install and simultaneous resorting design
  • Primary sorting occurs on higher-level belt and aggressively removes all potential defects (may include false rejects)
  • Secondary sorting on lower-level belt receives rejects from primary sorting for false-reject recovery
  • High-capacity waterproof vibratory feeder evenly distributes IQF vegetables and fruit into a single layer to minimize overlapping
  • Reinforced food-grade stainless steel structure and sealed scanning and control boxes withstand frequent high-pressure washing and sterilization
  • Quick belt change ensures convenient routine maintenance and cleaning, meeting higher food safety and hygiene standards
  • Field-proven Humidity Control System integrated maintains consistent performance and minimizes downtime
  • Modular design of belt width from 600 to 1800mm (600/1200/1800) provides processors more flexibility
AI Powered 4-in-1 Inspection System
  • Proprietary AI Deep Learning algorithms continuously improves defect recognition based on new samples
  • High-Resolution RGB Camera System
  • High-Intensity LED Illumination System

Market-leading precise detection to a wide range of defects in IQF vegetables and fruit by color, size, shape and texture features:

  • Color Defects:
    • Discoloration, mold, rot
  • Shape Defects:
    • Misshapen, deformed, oversized, undersized, broken
  • Surface Damage:
    • Bruises, cuts, abrasions, crushing, scars, cracks, shriveling
  • Biological Contaminants:
    • Insect damage, leaf/stem residues, other vegetable debris, soil clumps
  • Foreign Materials:
    • Stones, plastic/rubber fragments, wood chips
Raspberry Cranberry Sorter IQF Fruit Sorting Equipment Automatic
Specifications
Model Belt Width (mm) Air Nozzle Air Pressure (mpa) Air Consumption (m³/min) Voltage Power (kw) Dimension (mm) Unpacked Weight (kg)
HDF2 600 256 0.6-0.8 <2.1 220V~50/60Hz 6.6 4686×1924×2685 1589
HDF4 1200 512 0.6-0.8 <4.1 220V~50/60Hz 8.3 5087×2524×2685 2165
HDF6 1800 768 0.6-0.8 <4.1 220V~50/60Hz 11.8 4998×2963×2685 2419
