VGV AI Optical Sorter Machine Precision Automatic Fruit Sorting Machine
VGV AI Optical Sorter Machine Precision Automatic Fruit Sorting Machine
Specifications
Air Nozzle :
64
Voltage :
220V~ 50/60Hz
Power (kW) :
0.9
Brand Name :
PHOENIX
Model Number :
VGV AI Optical Sorter
Place of Origin :
Hefei
MOQ :
1
Price :
Price Negotiable
Payment Terms :
L/C,D/A,D/P,,T/T,
Delivery Time :
5-8 work days
Model :
VGV1
Description
VGV AI Optical Sorter AI Powered High-precision Defect Removal And Quality Grading With Industry-leading Accuracy For Dehydrated Vegetables
Technical Features
Tailored Sorting Solution for Dehydrated Vegetables
  • Optional innovative high-capacity 2-layer vibratory feeder evenly distributes dehydrated vegetables into a single layer to minimize overlapping
  • Sealed scanning and control boxes provide machine with high-level dust protection
  • Field-proven Dust Control System integrated maintains high operation reliability and performance consistency, and minimizes downtime
  • Modular design of vertical frame size from 1 to 12 chutes (1/4/6/8/10/12) provides processors more flexibility
AI Powered 4-in-1 Multispectral Inspection System
  • Proprietary AI Deep Learning algorithms continuously improves defect recognition based on new samples
  • High-Resolution RGB Camera System
  • High-Intensity LED Illumination System
  • Optional InGaAs-SWIR Camera System
  • Optional UV Fluorescence Camera System
Market-leading precise detection to a wide range of defects of dehydrated vegetables by color, size, shape and texture features:
  • Color Defects: Browning, discoloration, charred spots, mold, skin residues
  • Shape Defects: Broken fragments, clumped pieces, deformed shapes, oversized, undersized
  • Drying Defects: Uneven dehydration, sugar crystallization, rehydration stains
  • Foreign Material Contamination: plastic/rubber fragments
  • Biological Contamination: Microbial colonies
High-Performance Ejector System
  • Engineered for enhanced durability, optimized speed and air consumption
  • Accurate rejection and reliable performance at high-capacity sorting
  • Significant reduction in false rejection rate and total cost of ownership
VGV AI Optical Sorter Machine Precision Automatic Fruit Sorting Machine
Specifications
Model Chute Air Nozzle Air Pressure (MPa) Air Consumption (L/min) Power (kW) Voltage Dimension (LWH)(mm) Weight* (kg)
VGV1 1 64 0.6~0.8 <1000 0.9 220V~ 50/60Hz 1255×2199×2076 680
VGV4 4 256 0.6~0.8 <2000 2.9 220V~ 50/60Hz 2170×2199×2076 1150
VGV6 6 384 0.6~0.8 <3000 4.4 220V~ 50/60Hz 2800×2199×2076 1480
VGV8 8 512 0.6~0.8 <4000 5.9 220V~ 50/60Hz 3430×2199×2076 1840
VGV10 10 640 0.6~0.8 <5000 7.3 220V~ 50/60Hz 4070×2199×2076 2180
VGV12 12 768 0.6~0.8 <6000 8.8 220V~ 50/60Hz 4835×2199×2076 2550
