PET Flakes Sorting Machine VPMC SWIR Polymer Sorter Stainless Steel
PET Flakes Sorting Machine VPMC SWIR Polymer Sorter Stainless Steel
Specifications
Brand Name :
PHOENIX
Place of Origin :
Hefei
MOQ :
1
Price :
Price Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Delivery Time :
5-8 work days
Model Number :
VPMC SWIR Sorter
Recognition Method :
Image Recognition, Using AI Models
Weight :
660(kg)
Dimensions :
1135×1928×2385
Material :
Stainless steel
Display :
High resolution touch screen
Air Pressure (MPa) :
0.6~0.8
Description
VPMC SWIR SorterPremium Detection Of Both Polymer And Color To Plastic Flakes; Separation Of PET Flakes From Non-PET Polymers
Specifications
Model Chute Air Nozzle Throughput
(t/h)		 Air Pressure
(MPa)		 Air Consumption
(m³/min)		 Power
(kW)		 Unpacked Weight
(kg)		 Dimension
(mm)
VPMC1 1 64 0.2~0.8 0.6~0.8 <0.5 1.3 660 1135×1928×2385
VPMC4 4 256 0.8~3.0 0.6~0.8 <2.0 5.7 1241 1936×2110×2409
VPMC6 6 384 1.0~4.0 0.6~0.8 <3.0 7.6 1620 2566×2110×2409
VPMC8 8 512 2.0~6.0 0.6~0.8 <4.0 9.6 2035 3256×2110×2409

Technical Features

  • Tailored Sorting Solution for Polymer and Color Detection to Plastic Flakes
    • Innovative high-capacity 2-layer vibratory feeder evenly distributes plastic flakes into a single layer to minimize overlapping
    • Sealed scanning and control boxes provide machine with high-level dust protection
    • Field-proven Dust Control System integrated maintains high operation reliability and performance consistency, and minimizes downtime
    • Modular design of vertical frame size from 4 to 8 chutes (4/6/8) provides processors more flexibility
  • Premium Industrial Inspection System
    • Dual-Band InGaAs-SWIR Camera System
      • Accurate detection to polymer types (PET/HDPE/PP/ABS/PC/PS/PMMA, etc.) based on molecular composition
      • Stable Air Cooling System maintains InGaAs sensor and Halogen Lighting System stabilities in hot environments
    • High-Resolution RGB Camera System
      • High-precision identification of color variations and contaminants
      • High-Intensity LED Illumination System enables detection to subtle color differences, minimizing false rejects
