Precision Detection AI SWIR Sorter Machines PET Bottle Sorting Machine
Precision Detection AI SWIR Sorter Machines PET Bottle Sorting Machine
Specifications
Display :
High resolution touch screen
Recognition Method :
Image Recognition, Using AI Models
Control System :
PLC with Touch Screen Interface
Dimension (mm) :
9600×2000×2900
Unpacked Weight (kg) :
4000
Power (kW) :
7
Brand Name :
PHOENIX
Model Number :
HPB AI-SWIR Sorter
Place of Origin :
Hefei
MOQ :
1
Price :
Price Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,,
Delivery Time :
5-8 work days
Description
HPB AI-SWIR SorterAI Powered Precision Detection By Color, Polymer, Label And Shape: Recovery Of PET Bottles And Other Plastic Bottles
Technical Features
  • Technical Features
    • Dual-Sensor Simultaneous Detection
      • Superior InGaAs-SWIR Camera System detects polymer types (PET/HDPE/PP, etc.) based on molecular composition
      • High-resolution RGB Camera System detects color variations (clear/blue/green/contaminated bottles)
    • AI Deep Learning
      • Automatically classifies bottles, caps, labels and contaminants (metal, silicone)
      • Self-learning for new materials and complex patterns (e.g., printed-label bottles)
      • Adapts to challenging scenarios (reflective/black/crushed bottles)
    • High-Performance Belt Sorting
      • Modular belt system: 2-6 tons/hour capacity
      • 88-224 nozzles with ≤1ms response & ±2mm ejection accuracy
      • Modular design of belt width from 1200 to 2800mm (1200/2000/2800) provides processors more flexibility

Precision Detection AI SWIR Sorter Machines PET Bottle Sorting Machine

Specifications
Model Belt Width (mm) Air Nozzle Throughput (t/h) Air Pressure (MPa) Air Consumption (m³/min) Power (kW) Unpacked Weight (kg) Dimension (mm)
HPB1 1200 88 1.5~3.0 0.6~0.8 <3.5 7 4000 9600×2000×2900
HPB2 2000 160 3.0~4.0 0.6~0.8 <6.5 12 5000 9600×3200×2900
HPB3 2800 224 4.0~6.0 0.6~0.8 <9.0 16 6500 9600×4000×2900
