RGB Plastic Color Sorter Machine VPC Optical Sorting Machine
RGB Plastic Color Sorter Machine VPC Optical Sorting Machine
Specifications
Brand Name :
PHOENIX
Model Number :
VPC Optical Sorter
Place of Origin :
Hefei
MOQ :
1
Price :
Price Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Delivery Time :
5-8 work days
Condition :
New
Name :
orange
Throughput (t/h) :
0.4-0.8
Air Pressure (MPa) :
0.6-0.8
Dimension (mm） :
1255×1670×1995
Power (kW) :
0.9
Description
VPC Optical SorterAccurate Color Detection To Plastic Flakes With RGB Camera System; Purifying High-value Color Flakes From Plastic Mix
Technical Features
  • Tailored Sorting Solution for Color Detection to Plastic Flakes

    • High-capacity vibratory feeder evenly distributes plastic flakes into a single layer to minimize overlapping

    • Sealed scanning and control boxes provide machine with high-level dust protection

    • Field-proven Dust Control System integrated maintains high operation reliability and performance consistency, and minimizes downtime

    • Modular design of vertical frame size from 4 to 10 chutes (4/6/8/10) provides processors more flexibility

  • Reliable Industrial Inspection System

    • High-Resolution RGB Camera System differentiate colors for high-purity output

    • Optional NIR Camera System identifies light-yellow, light-blue and low-density aluminum flakes

    • High-Intensity LED Illumination System enables detection to subtle color differences, minimizing false rejects

RGB Plastic Color Sorter Machine VPC Optical Sorting Machine

Specifications
Model Chute Air Nozzle Throughput (t/h) Air Pressure (MPa) Air Consumption (m³/min) Power (kW) Unpacked Weight (kg) Dimension (mm)
VPC1 1 64 0.4-0.8 0.6-0.8 <1.0 0.9 680 1255×1670×1995
VPC4 4 256 1.5-3.0 0.6-0.8 <2.0 2.9 1160 2170×1823×2007
VPC6 6 384 2.0-4.0 0.6-0.8 <3.0 4.4 1390 2438×1823×2007
VPC8 8 512 3.0-6.0 0.6-0.8 <4.0 5.9 1750 3064×1823×2007
VPC10 10 640 4.0-8.0 0.6-0.8 <5.0 7.3 2138 3734×1823×2007
