Double Layer Dry & Wet Ore Sorting Machine Stone Color Sorter
Double Layer Dry & Wet Ore Sorting Machine Stone Color Sorter
Specifications
Brand Name :
PHOENIX
Model Number :
HDF AI Optical Sorter
Place of Origin :
Hefei
MOQ :
1
Price :
Price Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Delivery Time :
5-8 work days
Model :
HDF5
Voltage :
220V ~ 50/60Hz
Description

HDF Ore Stone Color Sorter Machine

HDF ore stone color sorter machine

Providing sorting solutions for the ore size range from 30-100mm

Product Description

HDF Series 30-100mm Ore Stone Color Sorter integrates advanced visible-light sorting technology. The KD4 efficiently sorts large raw ore stones, fully replacing manual selection. It handles wet or water-containing ores and performs pre-selection and roughing based on ore color differences. Ideal for non-metallic minerals like quartz, feldspar, calcite, and marble, as well as metal ores including tungsten, manganese, molybdenum, lead, zinc, copper, silver, tin, and hematite.

Our Advantages

  • Achieve big size ore sorting (30-100mm) by adopting China domestic initiative energy aggregating ejectors.
  • Ultra-wide track conveyor, large output, and stable.
  • The new shadowless light technology, solve the problem of large particle ore shadow, greatly improve the recognition rate.
  • Advanced AI algorithm for intelligent sorting of complex materials.

Sorting Applications

Double Layer Dry & Wet Ore Sorting Machine Stone Color Sorter

Specifications

Model Belt Width (mm) Air Nozzle Air Pressure (MPa) Air Consumption (L/min) Voltage Power (kW) Dimension (mm) Unpacked Weight (kg)
HDF5 1500 192 0.6~0.8 <6000 220V ~ 50/60Hz 12 3777×2172×2309 2800
