220V Ore Sorting Equipment 2mm-70mm Particles Color Sorter Machines
220V Ore Sorting Equipment 2mm-70mm Particles Color Sorter Machines
Specifications
Brand Name :
PHOENIX
Model Number :
HDF AI Optical Sorter
Place of Origin :
Hefei
MOQ :
1
Price :
Price Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Delivery Time :
5-8 work days
Model :
HDF5
Belt Width (mm) :
1500
Air Pressure (MPa) :
0.6~0.8
Voltage :
220V ~ 50/60Hz
Description
HDF Double-Layer Dry & Wet Ore Sorting Machine

HDF double-layer ore sorting machine is designed for the purification of 2-70mm dry & wet ore particles with high performance.

The fast belt-type ore machine HDF is designed for the separation and purification of metallic and non-metallic ores in dry & wet separation processes. HDF ore sorting machine is perfectly suited to the sorting requirements of quartz ores, barite, potassium feldspar, etc.

Technicial Application
  • Widely applicable to the sorting of non-metallic ores, metallic ores and other materials.
  • It is suitable for separating large particles of 2-70mm size, wet ore, dry ore, etc.
  • The new structure solves the problem of mutual adhesion between ore and belt in the process of ore processing, etc.
Our Advantages
  • Multi-optical path compensation system for finer detection and more stable operation.
  • New structure plus high speed spray valve for more accurate rejection and lower loss.
  • Open far-focus design, new dust cleaning and dust removal system, making machine operation more stable.
  • Ore specific AI algorithm, combined with remote APP, makes detection more intelligent and operation more convenient.
  • The whole machine adopts a new ore-specific system with optional deep learning module, which makes the sorting range wider and the operation more efficient.
Sorting Applications

220V Ore Sorting Equipment 2mm-70mm Particles Color Sorter Machines

Specifications
Model Belt Width (mm) Air Nozzle Air Pressure (MPa) Air Consumption (L/min) Voltage Power (kW) Dimension (mm) Unpacked Weight (kg)
HDF5 1500 192 0.6~0.8 <6000 220V ~ 50/60Hz 12 3777×2172×2309 2800
