HDF AI-powered Optical Sorter with Dual-band SWIR and 400mm Belt Width for Precision Nut Sorting
HDF AI-powered Optical Sorter with Dual-band SWIR and 400mm Belt Width for Precision Nut Sorting
Specifications
Brand Name :
PHOENIX
Model Number :
HDF
Place of Origin :
Hefei
MOQ :
1
Price :
Price Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Delivery Time :
5-8 work days
Model :
HWN1
Belt Width (mm) :
400
Air Nozzle :
80
Air Pressure (MPa) :
0.6~0.8
Air Consumption (m³/min) :
<1.2
Voltage :
220V~50/60Hz
Description
HDF Intelligent Optical Sorter – Revolutionizing Nut Sorting with AI

Designed for high-end nut processors, it combines artificial intelligence with advanced optical technology to achieve comprehensive and precise sorting of surface, chemical, and internal quality—enhancing product quality, efficiency, and safety.

Specifications
Model Belt Width (mm) Air Nozzle Air Pressure (MPa) Air Consumption (m³/min) Voltage Power (kW) Dimension (mm) Unpacked Weight (kg)
HWN1 400 80 0.6~0.8 <1.2 220V~50/60Hz 5.2 3960×1201×2415 960
HWN2 800 160 0.6~0.8 <2.4 220V~50/60Hz 6.3 3960×1601×2415 1185
HWN3 1200 240 0.6~0.8 <3.6 220V~50/60Hz 7.5 3960×2001×2415 1340
HDF AI-powered Optical Sorter with Dual-band SWIR and 400mm Belt Width for Precision Nut Sorting
Core Advantages: AI + Dual-Band SWIR + RGB Optical System
  • AI-powered deep learning algorithms: Continuously optimized with new samples, defect recognition becomes more accurate over time.
  • Dual-band SWIR camera system: Breaks through the limitations of visible light, detecting chemical composition and moisture content.
  • High-resolution RGB color imaging: Precisely captures color, size, and shape information.
  • Multi-dimensional detection: Integrates color, shape, chemical composition, moisture, and other data, significantly surpassing the accuracy of traditional RGB sorters.
Exceptional Optical Sorting Capabilities
✅ Deep Defect Detection
  • Identifies hidden mold, insect damage, and rancidity undetectable by RGB cameras.
  • Enhanced early detection of aflatoxin to prevent risks proactively.
✅ Ultra-Precise Foreign Material Removal
  • Reliably removes plastics, stones, glass, and metals similar in color to nuts.
  • Ultra-high precision in identifying shell fragments and pit residues, reducing impurity rates.
✅ Efficiency and Stability
  • High-capacity operation with industry-leading sorting speed.
  • Minimal manual intervention, continuously reducing labor costs.
Built for Demanding Production Environments
  • Industrial dust-proof design: Sealed sorting chamber and electrical cabinet, resilient in high-dust environments.
  • Integrated dust removal and air-cooling systems: Ensures continuous and stable operation.
  • Efficient vibrating feeding system: Achieves single-layer uniform distribution of nuts, reducing overlap and improving detection accuracy.
  • Modular flexible configuration: Belt widths of 400/800/1200mm available to adapt to different production line capacities.
High-Performance Ejection and Intelligent Control
