Specifications
Place of Origin :
Sichuan，China
Brand Name :
XBSY
Certification :
USE 18000,USE14000，EAC，CE，ISO9000
MOQ :
1
Packaging Details :
Ply Wood Box,iron box
Delivery Time :
1-2 months
Payment Terms :
TT
Supply Ability :
1000
Price :
Price Negotiable
Model :
SB6 × 8J
Flow (m³/h) :
200-240
Head (m) :
33-37
Rotational Speed(rpm) :
1480-1780
Efficiency (%) :
64-67
Power (kW) :
28-75
Weight (kg) :
850-1130
Description

​​High-Efficiency SB Mud Pumps: 80+ Specs, Metric/Imperial, Dual Rotation​

The SB Series centrifugal mud pumps (SB6×8 to SB2×3) deliver unmatched reliability for drilling solids control. Featuring 80+ configurations (4-75kW), these pumps support direct or belt drives and dual rotation modes. The SB6×8J-13 model achieves 240m³/h flow and 37m head at 67% efficiency, with a 75kW motor. Compact dimensions (2056×698×1022mm) and weights up to 1130kg ensure easy rig integration. Patented seal technology (ZL200720079857.2) extends service life 6x beyond industry standards.

Dual Rotation​ Centrifugal Pumps 200m3/H - 240m3/H Horizontal Centrifugal Pump

Features
Patented Seal Technology - Service life is 6 times longer than an ordinary mechanical seal. (Patent No. ZL200720079857.2)
High Efficiency - The impeller and pump shell port are designed with optimal streamlining.
Long Service Life - The overflow parts are made of highly wear-resistant cast iron.
Non-clogging - The impeller is designed with a wide flow path.
Patented Appearance - Compact and reasonable structure (Patent No. ZL200730094452.1).

Model Flow (m³/h) Head (m) Rotational Speed(rpm) Efficiency (%) Power (kW) Weight (kg) L*W*H (mm)
/ / / 50Hz 60Hz / Shaft Power Motor Power / /
SB6 × 8J - 13 240 37 1480 1780 67 36 75 1130 2056×698×1022
SB6 × 8J-12½ 200 36 1480 1780 66 29.7 55 1000 1996×698×972
SB6 × 8J - 12 200 33 1480 1780 64 28 45 850 1916×638×917
