135kg 60HZ Drilling Mud Agitator Single Double Wave Wheel Low Noise Mud Tank Agitator
135kg 60HZ Drilling Mud Agitator Single Double Wave Wheel Low Noise Mud Tank Agitator
135kg 60HZ Drilling Mud Agitator Single Double Wave Wheel Low Noise Mud Tank Agitator
135kg 60HZ Drilling Mud Agitator Single Double Wave Wheel Low Noise Mud Tank Agitator
135kg 60HZ Drilling Mud Agitator Single Double Wave Wheel Low Noise Mud Tank Agitator
135kg 60HZ Drilling Mud Agitator Single Double Wave Wheel Low Noise Mud Tank Agitator
135kg 60HZ Drilling Mud Agitator Single Double Wave Wheel Low Noise Mud Tank Agitator
135kg 60HZ Drilling Mud Agitator Single Double Wave Wheel Low Noise Mud Tank Agitator
Specifications
Place of Origin :
Sichuan，China
Brand Name :
XBSY
Certification :
USE 18000,USE14000，EAC，CE，ISO9000
MOQ :
1
Packaging Details :
Ply Wood Box,iron box
Delivery Time :
1-2 months
Payment Terms :
TT
Supply Ability :
1000
Price :
Price Negotiable
2870 :
500
Model :
JB / W2.2
Motor Power :
2.2
Motor Speed :
1420 / 1740
Impeller Speed (rpm) :
57 or 71
Impeller Discharge :
2870
Weight (kg) :
135
L × W × H (mm) :
817×494×498
Description

JB/W Series Drilling Mud Agitator | Single/Double Wave Wheel | Low Noise Design

The XBSY JB/W series mud agitator ensures consistent drilling fluid homogeneity and solid suspension through its inclined blade design. Engineered for reliability, it operates at 57 RPM (50Hz) or 71 RPM (60Hz) with a 2870 impeller discharge capacity. The worm/turbine reducer minimizes noise and maintenance needs, while the 500mm impeller diameter optimizes mixing efficiency. Suitable for both land-based tanks and offshore platforms, models range from JB/W2.2 to JB/W22 (2.2-22KW), supporting global power grid standards. Weight: 135kg; Dimensions: 817×494×498mm.

135kg 60HZ Drilling Mud Agitator Single Double Wave Wheel Low Noise Mud Tank Agitator

Features
Reliable Operation - good performance, low maintenance and low noise with worm/turbine reducer.
Good Mixing Effect - The use of inclined blades - Nice stirring and mixing effect.
Wide Range of Application - Diversified structure, widely used in land mud tanks and offshore platforms.

Model Motor Power Motor Speed Impeller Speed (rpm) Impeller Discharge Impeller Diameter (mm) Weight (kg) L × W × H (mm)
/ / / 50HZ 60HZ / Single Impeller Double Impeller / /
JB / W2.2 2.2 1420 / 1740 57 or 71 70 2870 500 - 135 817×494×498
