2279mm Monocrystalline Solar Photovoltaic Panels For Residential Commercial
2279mm Monocrystalline Solar Photovoltaic Panels For Residential Commercial
2279mm Monocrystalline Solar Photovoltaic Panels For Residential Commercial
2279mm Monocrystalline Solar Photovoltaic Panels For Residential Commercial
2279mm Monocrystalline Solar Photovoltaic Panels For Residential Commercial
2279mm Monocrystalline Solar Photovoltaic Panels For Residential Commercial
Specifications
Brand Name :
welons
Model Number :
Custom
Certification :
CE ROHS FCC
Place of Origin :
China
MOQ :
100 pcs
Payment Terms :
T/T
Maximum Power :
550W
Module Dimension :
2279×1134×30mm
Weight :
27KG ±3%
Operating Temperature :
-40°C ~ +85°C
Price :
USD 30-300 /pcs
Packaging Details :
1.2mX2.4m wooden Case packaging
Delivery Time :
5-8 work days
Supply Ability :
500000 pcs per year
Description
550W Solar panel Solar power generation panel Photovoltaic solar panel Monocrystalline component High conversion rate

This monocrystalline PV module delivers stable, high-yield power generation for residential, commercial, and industrial solar systems. Built with premium Grade A mono solar cells and advanced encapsulation technology, it ensures long service life, excellent weather resistance, and reliable performance even in low-light environments.

Parameter Details
Cell Type Monocrystalline (182mm Multi-Busbar)
Module Dimension 2279*1134*30mm
Weight 27KG ±3%
Structure 3.2mm High-Transmittance AR Coated Tempered Glass + EVA Film + White Backsheet
Frame Anodized Aluminum Alloy
Junction Box 3-part, IP68 Protection Rating
Cable 4.0mm², (+) 280mm / (-) 280mm (Customizable)
Connector Original MC4 / MC4 Compatible
Mechanical Load Front 5400Pa / Rear 2400Pa (Static Pressure)
Key Features
  • High Power Output: 550W rated power with efficient energy conversion rate up 23.5%.
  • Premium Grade A Mono Cells: Low attenuation, high stability, long lifespan.
  • Half-Cut Design: Better anti-shading performance, higher reliability.
  • Durable Construction: Tempered glass, aluminum frame, wind and snow load resistant.
  • IP68 Waterproof & Dustproof: Suitable for outdoor harsh environments.
  • IEC & CE Certified: Safe, reliable, and compatible with global standards.
  • 25-Year Linear Power Warranty: Stable output and long-term investment protection.
Applications
  • Residential rooftop solar systems
  • Commercial & industrial rooftop PV
  • Solar power stations
  • Off-grid and hybrid solar systems
  • Agricultural PV, carports, and BIPV projects
Specifications (General)
  • Maximum Power (Pmax): 550W
  • Cell Type: Monocrystalline
  • Panel Type: Half-cut mono
  • Glass: 3.2mm high-transmittance tempered glass
  • Frame: Anodized aluminum alloy
  • Operating Temperature: -40°C ~ +85°C
  • Warranty: 25-year performance warranty
