16S1P 280Ah LiFePO4 Battery Storage 14336Wh Household Solar Batteries
16S1P 280Ah LiFePO4 Battery Storage 14336Wh Household Solar Batteries
16S1P 280Ah LiFePO4 Battery Storage 14336Wh Household Solar Batteries
16S1P 280Ah LiFePO4 Battery Storage 14336Wh Household Solar Batteries
16S1P 280Ah LiFePO4 Battery Storage 14336Wh Household Solar Batteries
16S1P 280Ah LiFePO4 Battery Storage 14336Wh Household Solar Batteries
16S1P 280Ah LiFePO4 Battery Storage 14336Wh Household Solar Batteries
16S1P 280Ah LiFePO4 Battery Storage 14336Wh Household Solar Batteries
Specifications
Energy :
14336Wh
Normal capacity :
280Ah
Operation temperature：Charge :
0~55℃
Allowed MAX discharge current :
200Adc
End of dis charge voltage :
40Vdc
Cell :
280Ah
DC normal charge voltage :
58.4+2Vdc
Communication method :
RS232/CAN/RS485
Self-discharge rate：Recover capacity :
≤1.5%/Month；≤8% year
Combination :
16S1P
Additional Function :
Balance
Internal resistance :
≤50mΩ @1kHZ AC
Cooling method :
Natural cooling
Storage environment：≤1month :
-20~+60℃、5~75%RH
Capacity Nominal :
280Ah
Minimum capacity :
271.6Ah(≥97%)
Voltage range :
40V-58.4Vdc
Operation temperature：Discharge :
-20~55℃
Voltage Nominal :
51.2V
Nominal energy :
14.336KWh
Rated Voltage :
51.2Vdc (LFP-16S)
Dimension :
L 500±10mm，W 300mm±10mm，H 850mm±10mm
Storage environment：≥3month :
-10~+45℃、5~75%RH
Compose method :
16S1P
Weight :
About 124kg
Description :
Rechargeable LiFePO4 battery pack
DC foat charge voltage :
58.4+2Vdc
BMS :
16S200A
IP rating :
IP55
Protection :
Over Charge Protection, Over Discharge Protection, Over Curent Protection，Short Protection, Temperature protection, etc
Storage environment：Recommend environment :
15~35℃、5~75%RH
Recommended charge current :
≤100Adc
Self-discharge rate：Residual capacity :
≤3%/Month；≤15%/ year
Chemistry :
LiFePO4
Alowed MAX charge current :
200Adc
Description

CN551601: 51.2V 280Ah LiFePO4 Battery Pack

The CN551601 is a high-performance rechargeable Lithium Iron Phosphate (LiFePO4) battery pack designed for robust energy storage. Featuring an integrated 16S200A BMS, it ensures real-time monitoring and comprehensive protection against overcharging, overdischarging, overcurrent, and extreme temperatures.

Key Advantages

  • Intelligent BMS: Real-time status monitoring with automatic safety cut-off.
  • High Energy Density: 14.336KWh nominal energy capacity.
  • Advanced Connectivity: Supports RS232, CAN, and RS485 communication protocols.
  • Durability: IP55 rated enclosure for reliable operation in diverse environments.

Product Attributes

ChemistryLiFePO4
Nominal Voltage51.2V
Nominal Capacity280Ah
Cooling MethodNatural Cooling

Technical Specifications

Parameter Detail
Combination 16S1P
Nominal Energy 14.336KWh
Voltage Range 40V - 58.4Vdc
Dimensions 500 x 300 x 850 mm (±10mm)
Weight Approx. 124kg
IP Rating IP55
Charge Temp 0 ~ 55℃
Discharge Temp -20 ~ 55℃
