8200W Solar Energy Inverter MPPT SCC/AC Charger Photovoltaic Inverter
8200W Solar Energy Inverter MPPT SCC/AC Charger Photovoltaic Inverter
8200W Solar Energy Inverter MPPT SCC/AC Charger Photovoltaic Inverter
8200W Solar Energy Inverter MPPT SCC/AC Charger Photovoltaic Inverter
8200W Solar Energy Inverter MPPT SCC/AC Charger Photovoltaic Inverter
8200W Solar Energy Inverter MPPT SCC/AC Charger Photovoltaic Inverter
Specifications
Dimension(D*W*H) :
435*306*110mm
Peak Efficiency :
≥93%
Max Charging Current :
140Amp
Operating Temperature Range :
-10°C ~ 50°C
Input Voltage Waveform :
Sinusoidal
Output Frequency :
50Hz
Humidity :
5% to 95% Relative Humidity (Non-condensing)
Efficiency (Line Mode) :
>95%
Output Voltage Regulation :
230Vac+5%
Storage temperature :
-15°C~ 60°C
Transfer Time :
10ms typical
Output Voltage Waveform :
Pure Sine Wave
INVERTER MODEL :
8.2KW
Nominal Input Frequency :
50Hz/60Hz
PV Array MPPT Voltage Range :
60Vdc-450Vdc
Max. PV Array Open Circuit Voltage :
500Vdc
No Load Power Consumption :
56W
Net Weight :
10kg/pcs
Safety Certification :
CE
Max. PV Array Power :
8200W
Nominal Input Voltage :
230Vac
Nominal Py Voltage :
240Vdc
Rated Output Power :
8.2KW
Nominal DC Input Voltage :
48Vdc
Description
8200W Solar energy inverter/MPPT SCC/AC Charger/Photovoltaic inverter

8200W Multi-Functional Solar Inverter/Charger

The 8200W solar inverter is a high-performance, multi-functional inverter/charger designed to provide reliable, uninterrupted power. By integrating an inverter, solar charger, and battery charger into one unit, it ensures seamless energy management for your electrical devices. Featuring a comprehensive LCD display, it offers users intuitive customization and convenient button operation.

  • All-in-One Integration: Combines inverter, solar charger, and battery charger functions.
  • User-Friendly Interface: Comprehensive LCD display with easy-to-use controls.
  • Reliable Performance: Delivers consistent, uninterrupted power for critical applications.

Product Attributes

Unit: Piece
Dimensions: 435*306*110mm
Net Weight: 10kg per unit

Technical Specifications

Parameter Detail
Rated Output Power 8200W
Input Voltage Waveform Sinusoidal
Output Voltage Waveform Pure Sine Wave
Max. PV Array Power 8200W
PV MPPT Voltage Range 60Vdc-450Vdc
Max Charging Current 140Amp
Efficiency (Line Mode) >95%
Operating Temperature -10°C ~ 50°C
Safety Certification CE
