Specifications
Brand Name :
HXT
Model Number :
HXT-V330
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
1200
Payment Terms :
T/T
Supply Ability :
The production capacity is 80 units a month
Delivery Time :
5-15
Packaging Details :
Vacuum packing plus wooden box packing
PCB size :
80x50mm~460x330mm
Power :
220V/50HZ 320W
Dimension :
1950*1080*1250mm
Weight :
300kg
Lifting step :
10, 20, 30, 40, 50, adjustable
PCB thickness :
0.5-3.0mm
Description
Pcb Vacuum And Magazine Loader Suction And Delivery Machine Smt Pcb Transfer Machine Bare Board Loader SMD pcb Transfer Machine
Description

Closed sheet metal structure (safe and reliable) + aluminum profiles entering and exiting the frame, the surface is sprayed, and the color is white. Microcomputer PLC control system, stable and reliable work. Sensitive touch screen display operation, automatic fault diagnosis function, convenient man-machine dialogue.

A variety of sound and light and touch screen prompt alarm function.

The lifting step of the rack can be set according to the height of the components on the PCB.

With automatic counting function, it is convenient for production statistics. Special gas path, humanized design ensures that the PCB board will not be pushed and damaged, improving production efficiency.

Compatible with standard SMEMA interface.

The connecting device pushes the PCB board using a stepping motor.

The speed, distance and strength of the stepping motor push plate can be adjusted.

Conveyor belt speed adjustable. There are two function modes of vacuum suction board and board feeding, which can meet the board feeding operation of double-sided board and bare board at the same time.

The suction nozzle positioning adopts a universal mobile device, and the suction position can be adjusted at will according to the characteristics of the PCB board and the hole position.

The top safety cover can be opened to facilitate the handling of machine hardware during maintenance.

SMD Vacuum And Magazine Loader Suction Machine Smt Pcb Transfer Machine Bare Board Loader
Product Specification
Model 250 330 390
Applicable frame size 355*320*563mm 460*400*563mm 535*460*570mm
PCB size 50*50-350*250mm 50*50*460*330mm 50*50-535*390mm
Machine size 1650*880*1250mm 1950*1080*1250mm 2200*881280*1250mm
Machine weight 260KG 300KG 350KG
Power supply Single-phase AC220V 50Hz, 60Hz
Power 350W
Lifting step 10, 20, 30, 40, 50, the step distance can be set arbitrarily
Compressed air source 5-6kg
PCB board thickness 0.5-3.0mm
Fixed side Front fixation (rear fixation is optional)
Teleport height 900±20mm
Suction device Powerful nozzle head moves freely
Features Both single-sided and double-sided can be realized (single-sided can save board insertion time)
Transmission direction Left to right (optional right to left)
Withstand voltage AC terminal to ground 1500V for 1 minute
Use environment No corrosive gas and dust environment
Anti-jamming Voltage noise: 1000Vp-p, wave width 1us, time 1 minute
