SMTSX XY Movable Hot Bar Soldering Machine for High Productivity
Universal Hot Bar Soldering Machine Instroduction:

Hot Bar Reflow Soldering is a selective soldering process where two pre-fluxed, solder coated parts are heated using a heating element (called a thermode or a Hot Bar) to a sufficient temperature to melt the solder. The parts are then cooled below the solidification temperature to form a permanent electro-mechanical bond.

Universal Hot Bar Soldering Machine Features:
  1. According to different products, optional temperature for your choice.
  2. Unique material thermode head, ensure the average pressure.
  3. Has vacuum function, easier for adjustment and positioning.
  4. NC temperature, clear and high precision.
  5. With digital pressure gauge, pressure range can be preset.
  6. Programmable curve Including pre-heating and reflow soldering temperature.
  7. Suitable for all kinds of high density TAB, TCP and pressure to FPC, FFC and PCB soldering pressure welding.
  8. Precise PID control, phase angle replace pulse drive.
  9. Less Libration, less noise, avoiding voltage fluctuate
Universal Hot Bar Soldering Machine Specifications:
Model SMTSX
Machine size 680*650*600mm
Working area 250x250mm
Machine weight 163Kg
Working air pressure 0.6-0.8Mpa
Fixture quantity 1
Thermode head size Max 80*5mm
Welding precision pitch 0.2mm
Pressing time 1~99.9s
Temperature settings RT~500℃ tolerance ±3℃
Welding pressure 1~20Kg
Temperature settings 3-stage
Working environment 10-60℃,40%-95%
Power supply AC220V±10% 50HZ, 2000W
Alignment mode CCD + LCD Monitor
Feeding mode Manual
Starting mode Press start buttons
Rotation Platform Cylinder control, tolerance<0.02mm
Universal Hot Bar Soldering Machine Applications:

Easy to use, robust and economical for bonding flex to rigid assemblies such as flex to PCB, FPC to FPC, LCD-Flex to PCB, Flex to LCD, HSC to LCD, HSC to PCB, Wires to PCB.

This Hot Bar Soldering Machine offers a high-precision, high-volume solution for thermal bonding in electronics assembly.

SMTSX XY Movable Universal Hot Bar Soldering Machine for High Productivity
Application Area Details
FPC to PCB Soldering Attaching flexible circuits in smartphones, tablets, and wearables.
LCD / OLED Display Bonding Soldering COF (chip-on-film) or FOG (flex-on-glass) cables to display panels.
Ribbon Cable Termination Joining flat cables to connectors or circuit boards.
Repair Work Re-soldering connections in mobile devices, laptops, or small electronics.
Touch Panel Assembly Thermocompression bonding of touch sensor flexes to controller boards.
Automotive Displays Used in infotainment and dashboard electronics for bonding displays.
Medical Electronics Assembling compact, high-reliability medical devices.
Battery Pack Assembly Spot bonding of battery tabs or flexible sensors.
