330mm Pizza Cutter Manual V-cut PCB Separator Machine
330mm Pizza Cutter Manual V-cut PCB Separator Machine
330mm Pizza Cutter Manual V-cut PCB Separator Machine
330mm Pizza Cutter Manual V-cut PCB Separator Machine
Specifications
Brand Name :
Winsmart
Model Number :
SMTMD2
Certification :
CE
Place of Origin :
China
MOQ :
1 EA
Price :
USD1000-5000/EA
Payment Terms :
T/T
Supply Ability :
500 EA per year
Delivery Time :
2-3 working days
Packaging Details :
plywood case
Advantage :
Economic
Driving :
Manual
Blade Lifetime :
7-8 months
Blades Material :
japan high speed steel
Bladelength :
330mm
Minimize Thickness :
0.3-2.0mm
Application :
V-cut FR4 and MCPCB boards cutting
Name :
Manual PCB separator
Description
330mm Pizza Cutter Manual V-cut PCB Separator Machine
Manual PCB Separator Description:

This type of PCB separator is nicknamed a “pizza cutter” due to its circular blade that rolls through the V-groove, much like a pizza cutter slicing dough. It is a manual PCB depaneling tool designed for V-scored PCBs (i.e., PCBs with pre-cut V grooves).

Manual PCB Separator Features:
  1. Simple operation, speed is fast, to ensure that components of substrate are not injured by the movement.
  2. Linear blade slip speed can be manually controlled, the v-groove guiding device can be adjusted to the height, and can be more quickly adapted to substrate of different thickness.
  3. Reduce internal stress generated by the cutting board and avoid in cracking.
  4. Round blade can be used repeatedly after grinding.
  5. Support maxt 330mm long boards.
  6. Provides a smooth, burr-free finish while minimizing stress on the boards.
  7. The bottom blade helps to guide the PCB for consistent and straight cuts.
Manual PCB Separator Specifications:
Model SMTMD2
Machine dimension 800x260x350mm
Max cutting length 330mm
PCB material FR1, FR4
Cutting speed Manual control
PCB thickness 0.6-2.0mm
Power supply No required
Machine weight 40kgs
Wooden case dimension 85x50x50cm
Gross weight 65kgs
Manual PCB Separator Applications:

It is widely used in a lot of industries: LED Lighting, Consumer Electronics, Automotive Modules, etc.

The 330mm Pizza Cutter Manual V-Cut PCB Separator is a reliable, budget-friendly tool for separating V-scored PCBs with minimal stress and a clean finish. It’s best suited for manual assembly lines, prototype labs, and low-volume production environments that prioritize precision and simplicity.
