Ttlock Smart Lock Keyless Electronic Door Handle Fingerprint For Sliding Door

Feature

1. 1.Compatible with various mortise to fit 99% doors. European 2885/3585/ 4585/6085/7085/92;
2. 2.Unique stylish smaller panel, 315*42mm, it can be fit most of the wooden metal door or glass door; 3.Support with tuya and smart life app,no need gateway to connect wifi.
3. 4.support remote unlocking , remote check,unlocking records and receive unlocking notice real-time . 5.Patented handle design,suitable for left/right door;
4. 6.One-Touch-Access Biometric Fingerprint sensor on the reader,360 degree fingerprint recognition; 7.Suitable for sliding door, aluminium alloy glass door, wooden door, metal door, composite door;
5. 8.Zinc alloy material, the shell is strong and can withstand impact;
6. 9.Back-up USB external power supply interface, in case the power is dead;
7. 10.Support ODM/OEM; Custom panel logo,color box, IC card,user manual.

8. Products Description

9.
10.
11.
12. Specification

13. Model	D5	Battery	4*AAA
    Finish	black/silver	Lock Size	250*60*20mm
    Static current	≦50uA	Dynamic current	≦180mA
    Administrators number	9	Fingerprint number	50
    Password number	100	RFID Card number	100
    Fingerprint sensor	Semiconductor	Fingerprint identification Angle	360°
    False Rejection Rate	≦0.1%	False Recognition Rate	≦0.0001%
    Reaction Time	≦0.1 Second	Power type	6V
    Emergrncy power	5VDC	Working temperature	-10℃~60℃
    Working Relative Humidity	20%~90%RH	Human vocie	Yes
    Keyboard	Touch standard 12-bit keyboard	Password Length	6-8 digits
    Phantom password	16 digits	Low voltage alarm	4.6+0.2V
    Unlock time	≦1Second	Version 2.0	TT Lock Blue tooth / Hotel
    Version 0.2	8 languages	Version P01	10 languages ( Chinese + French )
    Version 0.3	TUYA ZIGBEE	Version 0.4	TUYA Blue tooth
    Version 0.5	TT Lock WIFI	Version 1.0	TUYA WIFI
