Specifications
Brand Name :
Sinuo
Model Number :
SN7716
Certification :
Calibration Certificate (Cost Additional)
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
15 Sets Per Month
Delivery Time :
30 Days
Packaging Details :
Plywood Case
Test bench dimension :
500 × 500 × 350mm
Chamber dimensions :
1250 × 700 × 1800mm
Test station :
Single station
Test items :
Upholstered furniture
Flow meter :
40-100m/min
Timer :
0-999 seconds
Combustion tube :
8.0±0.1 mm
Control method :
PLC control
Description

EN 1021-1 Upholstered Furniture Flammability Test Chamber For Seating Materials Fire Safety Test



Product Information:

The upholstered furniture flammability test chamber is suitable for assessing the flammability of a single material combination used in upholstery, such as coverings and fillings, or the entire seat, when exposed to a combustion source or potentially acting on any item of the furniture, which can generate heat energy within the range of a burning match.

Test principle: Simulate the flammability of relevant parts or the entire piece of furniture during normal use.

Standard: EN 1021-1, IS 15768, BS 5852, etc.


Technical Parameters:

Working voltage AC 220V/50Hz
Chamber dimensions (mm) 1250mm W× 700mm D×1800mm H
Test bench dimension (mm)

500 × 500 × 350mm
Test items Upholstered furniture
Test station Single
Electrical control method PLC intelligent integrated control, 7-inch touch interface operation, dual operation with infrared remote control.
Stainless steel combustion tube The outer diameter is (8.0±0.1) mm, the inner diameter is (6.5±0.1) mm, and the length is (200±5) mm.
Timer Adjustable from 0-999 seconds; automatic timer for engine shutdown.
Flow meter Adjustable from 40-100m/min
Lighting Configure 12W led spotlight
Safety protection

1. Strong exhaust fan with baffle structure, the exhaust will be turned on automatically when the test is over or an alarm is given.

2. Equipped with a smoke detector to detect smoke leakage

3. With activated carbon bag to filter waste gas
