China Manufacturer Customized Cheap High Loading Capacity Heavy Duty 3 Axle LPG Tank Semi Trailer 10-100 cbm capacity for sale
China Manufacturer Customized Cheap High Loading Capacity Heavy Duty 3 Axle LPG Tank Semi Trailer 10-100 cbm capacity for sale
China Manufacturer Customized Cheap High Loading Capacity Heavy Duty 3 Axle LPG Tank Semi Trailer 10-100 cbm capacity for sale
China Manufacturer Customized Cheap High Loading Capacity Heavy Duty 3 Axle LPG Tank Semi Trailer 10-100 cbm capacity for sale
China Manufacturer Customized Cheap High Loading Capacity Heavy Duty 3 Axle LPG Tank Semi Trailer 10-100 cbm capacity for sale
China Manufacturer Customized Cheap High Loading Capacity Heavy Duty 3 Axle LPG Tank Semi Trailer 10-100 cbm capacity for sale
China Manufacturer Customized Cheap High Loading Capacity Heavy Duty 3 Axle LPG Tank Semi Trailer 10-100 cbm capacity for sale
China Manufacturer Customized Cheap High Loading Capacity Heavy Duty 3 Axle LPG Tank Semi Trailer 10-100 cbm capacity for sale
China Manufacturer Customized Cheap High Loading Capacity Heavy Duty 3 Axle LPG Tank Semi Trailer 10-100 cbm capacity for sale
China Manufacturer Customized Cheap High Loading Capacity Heavy Duty 3 Axle LPG Tank Semi Trailer 10-100 cbm capacity for sale
China Manufacturer Customized Cheap High Loading Capacity Heavy Duty 3 Axle LPG Tank Semi Trailer 10-100 cbm capacity for sale
China Manufacturer Customized Cheap High Loading Capacity Heavy Duty 3 Axle LPG Tank Semi Trailer 10-100 cbm capacity for sale
Specifications
Use :
Truck Trailer
Type :
Semi-Trailer
Material :
Aluminum / Alloy
Size :
Customised
Max Payload :
25T
Place of Origin :
Hubei, China
Brand Name :
Huawin
Color :
Sliver or as customers' option
Logo :
Can Be Designed as Customers' Option
Axle :
3
King Pin :
JOST Brand 3.5" bolt-in
Suspension :
Mechinal Suspension
Certification :
ce
OE NO. :
Optional
Packaging Details :
Nude Pack. The packing shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland.
Port :
China Main Port
Supply Ability :
1000 Unit/Units per Month
Price :
$35,300.00 - $43,100.00/Units
Description

China Manufacturer Customized Cheap High Loading Capacity Heavy Duty 3 Axle LPG Tank Semi Trailer 10-100 cbm capacity for sale

Specifications

(1) LPG tank semi trailer
(2) 3 Axle
(3) Loading Capacity: 25000KG
(4) Total Volume: 58.3CBM
(5) Tank Body Material: 5mm or 6mm/Q235 carbon steel or Aluminum alloy
(6) Certification: ISO9001 CCC,SGS

Technical Parameters

Dimensions(length*width*height) 13000*2500*3995(mm)
Estimated Tare Weight 15514KG
Payload 24486KG
Total Weight 40000KG
Effective Volume 58.3CBM
Products LPG. Butane, Propane
Fluid property flammable
Design temperature -40°C to 50°C
Design pressure 1.61MPa
Corrosion allowance 1.0mm
Major materials of bearing pressure Tanker body:Q345R,2.5mm, End plate:Q345R, front:10mm, Rear:12.5mm,Main Beam:T700
Filling weight per volume 420Kg/m3
Maximum filling weight 24486Kg
Compartments One
Baffle inside the tank 14-off Aluminum bolted plate, thickness is 5mm
Shape Cylindrical, Ellipse head
Heat treatment Overall heat treatment in a furnace, 500°C to 560°C
Flaw detection 100% Flaw detection
Hydrostatic test 2.1MPa
Magnaflux Aim at welding place flaw detection can not cover
Manhole 1, On top
Safty Valve 1
Axles 3 13 TON
Suspension system 1 Leaf spring
Tyre 7 ISO Certificated 12 R22.5 vacuum with 9.00
Kingpin 1 90# and 50# Bolt-atble
Landing legs 1 28Ton
7-Pin Socket 1 24V 7-pin socket
LED Lamp 1 All kinds of lamp
Small Tool box 1
Wheel carrier 1
Fire extinguisher 2 With red box

China Manufacturer Customized Cheap High Loading Capacity Heavy Duty 3 Axle LPG Tank Semi Trailer 10-100 cbm capacity for saleChina Manufacturer Customized Cheap High Loading Capacity Heavy Duty 3 Axle LPG Tank Semi Trailer 10-100 cbm capacity for saleChina Manufacturer Customized Cheap High Loading Capacity Heavy Duty 3 Axle LPG Tank Semi Trailer 10-100 cbm capacity for saleChina Manufacturer Customized Cheap High Loading Capacity Heavy Duty 3 Axle LPG Tank Semi Trailer 10-100 cbm capacity for saleChina Manufacturer Customized Cheap High Loading Capacity Heavy Duty 3 Axle LPG Tank Semi Trailer 10-100 cbm capacity for saleChina Manufacturer Customized Cheap High Loading Capacity Heavy Duty 3 Axle LPG Tank Semi Trailer 10-100 cbm capacity for sale
