25 Degrees Conveyor Angle Large Capacity Mobile Compost Fertilizer Rotory Trommel Screen
25 Degrees Conveyor Angle Large Capacity Mobile Compost Fertilizer Rotory Trommel Screen
25 Degrees Conveyor Angle Large Capacity Mobile Compost Fertilizer Rotory Trommel Screen
25 Degrees Conveyor Angle Large Capacity Mobile Compost Fertilizer Rotory Trommel Screen
25 Degrees Conveyor Angle Large Capacity Mobile Compost Fertilizer Rotory Trommel Screen
25 Degrees Conveyor Angle Large Capacity Mobile Compost Fertilizer Rotory Trommel Screen
25 Degrees Conveyor Angle Large Capacity Mobile Compost Fertilizer Rotory Trommel Screen
25 Degrees Conveyor Angle Large Capacity Mobile Compost Fertilizer Rotory Trommel Screen
25 Degrees Conveyor Angle Large Capacity Mobile Compost Fertilizer Rotory Trommel Screen
25 Degrees Conveyor Angle Large Capacity Mobile Compost Fertilizer Rotory Trommel Screen
25 Degrees Conveyor Angle Large Capacity Mobile Compost Fertilizer Rotory Trommel Screen
25 Degrees Conveyor Angle Large Capacity Mobile Compost Fertilizer Rotory Trommel Screen
Specifications
Applicable Industries :
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops
Showroom Location :
Canada, United Kingdom, United States, Germany, Brazil, Mexico, Russia, Australia
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Marketing Type :
New Product 2023
Warranty of core components :
1 Year
Core Components :
Motor
Condition :
New
Place of Origin :
China
Brand Name :
sinolion
Voltage :
380v/415v/440v
Dimension(L*W*H) :
depends on models
Weight :
2200 KG
Warranty :
1 Year
Product name :
GTS 1540 mobile trommel screen compost rotary drum screen for sale
Application :
earth, sand, gravel, compost, wood chips, construction waste
Screen material :
steel bar, steel plate punch hole, steel wire woven, stainless steel
Conveyor Angle :
25 degrees
Screen size :
20*20mm
Discharge size :
as request
Screen thickness :
4mm
Spare parts supplying :
Lifelong Provide
Hopper Capacity :
6.3 yd³ (4.8 m3)
Hopper Width :
5' 6" (170 cm)
Price :
$24,610.00/sets >=1 sets
MOQ :
1 unit
Description
Product Overview

Large capacity mobile compost fertilizer rotory trommel screen for sale

This wheeled mobile trommel screen systems’ high flexibility and the comprehensive range of products, from the smallest screening machine with less than 1.8 tons to the largest with up to 20 tons, enable the company to serve customers from the gardening,landscaping, recycling, timber, civil engineering, glass and even gravel pits and quarries. This wheeled mobile machine are not only used in the processing of earth materials, but also in more specific fields of application, such as the extraction of recyclable fractions of plastics, foils and wood chips and in the processing of compost, milled material, building rubble, stones, gravel, as well as glass or even in the recycling of sandbags.
FEATURES AT A GLANCE
25 Degrees Conveyor Angle Large Capacity Mobile Compost Fertilizer Rotory Trommel Screen
Scope of application
Like all machines in the GTS series, the GTS 1540 not picky about sifting out waste and raw materials regards. It is equally suitable for compost, soil,light rubble, wood, biomass, sand and gravel etc.
Screening materials: earth, sand, gravel, compost, wood chips, construction waste, recycling material, slag, crushed stone and
stone in grain sizes from 2 mm to 80 mm
Advantages
·Quick change system for the sieve insert, optionally drum or star screen insert
·Large 2 m³ feed hopper with a loading height of just 1.8 m ·2.5 m long discharge belts with 1.75 m delivery height
·Electronic load control for a perfect screening result optimal throughput
·Perfect mobility thanks to compact transport dimensions
25 Degrees Conveyor Angle Large Capacity Mobile Compost Fertilizer Rotory Trommel Screen
25 Degrees Conveyor Angle Large Capacity Mobile Compost Fertilizer Rotory Trommel Screen
25 Degrees Conveyor Angle Large Capacity Mobile Compost Fertilizer Rotory Trommel Screen
25 Degrees Conveyor Angle Large Capacity Mobile Compost Fertilizer Rotory Trommel Screen
25 Degrees Conveyor Angle Large Capacity Mobile Compost Fertilizer Rotory Trommel Screen
25 Degrees Conveyor Angle Large Capacity Mobile Compost Fertilizer Rotory Trommel Screen
PRODUCT SPECIFICATIONS

MTS1540 Specifications

Dimensions
Trommel
A Operating Length
28' 2" (860 cm)
Trommel Diameter
4' 10" (150 cm)
B Operating Height
9' 35" (285.5cm)
Screening Area
202.8ft2 (18.84 m2)
C Travel Length
11' 65" (355 cm)
1＃Fines Conveyor
D Travel Height
8' 36" (255 cm)
Conveyor Length
11'5" (350cm)
E Travel Width
5' 6" (170cm)
Conveyor Width
11' 3" (100cm)
F Trommel Length
17' 8" (540 cm)
Conveyor Angle
17.85 degrees
G Hopper Length
9' 10" (300 cm)
2＃Fines Conveyor
H Fines Conveyor Height
5' 3" (160 cm)
Conveyor Length
11'5" (350cm)
Weight
Conveyor Width
11' 3" (100cm)
Machine Weight Approx
Conveyor Angle
17.85 degrees
Power train
Screen (Standard)
Horsepower
40hp (30 kW)
Screen size
20*20mm
Fuel Tank Capacity
13.2 USAgal (50 L)
Screen thickness
4mm
Feed System
Production
Hopper Capacity
6.3 yd³ (4.8 m3)
Screening Performance
78 yd³ (90 m³) per hour
Hopper Width
5' 6" (170 cm)
Actual output may vary due to moisture content, material density, material size, and support equipment)
Specifications subject to change without notice
Successful Project
25 Degrees Conveyor Angle Large Capacity Mobile Compost Fertilizer Rotory Trommel Screen
25 Degrees Conveyor Angle Large Capacity Mobile Compost Fertilizer Rotory Trommel Screen
Company Profile
25 Degrees Conveyor Angle Large Capacity Mobile Compost Fertilizer Rotory Trommel Screen
25 Degrees Conveyor Angle Large Capacity Mobile Compost Fertilizer Rotory Trommel Screen
25 Degrees Conveyor Angle Large Capacity Mobile Compost Fertilizer Rotory Trommel Screen
25 Degrees Conveyor Angle Large Capacity Mobile Compost Fertilizer Rotory Trommel Screen
25 Degrees Conveyor Angle Large Capacity Mobile Compost Fertilizer Rotory Trommel Screen
FAQ
1. What's the delivery time after I pay the deposit ?
In your first inquiry, please let us know your information and requirements, we will give you guidance for choosing the right
machine.

2. Is mineral samples analysis available?
Sure, we supply samples analysis service for free. After the testing, we will give you the reasonable flow chart, suitable
solution and equipment selection.

3. What's the delivery time after I pay the deposit?
We will clear delivery time in slaes contract, Single movable drum sieve often deliveried within 10-15 working days after receipt of the pre-payment. Complete production line will delivery within 25-40 working days after receipt of the pre-payment.

4. How long of your machine quality guarantee terms ?
Quality guarantee time is one year(wearing parts excluded).
