Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole
Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole
Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole
Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole
Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole
Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole
Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole
Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole
Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole
Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole
Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole
Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole
Specifications
Applicable Industries :
Building Material Shops, Manufacturing Plant, Construction works , Energy & Mining
Showroom Location :
Canada, United Kingdom, United States, Italy, Germany, Brazil, Mexico, Russia, Malaysia, Australia
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Marketing Type :
New Product 2023
Warranty of core components :
1 Year
Core Components :
PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pump
Condition :
New
Type :
Gravity Separator
Place of Origin :
China
Brand Name :
sinolion
Voltage :
380v/415v/440v
Dimension(L*W*H) :
depends on gold washing mining
Weight :
2000 KG
Warranty :
1 Year
Product name :
mobile without shaft trommel screen for compost, topsoil
Application :
waste sorting machine equipment
Power :
3-45KW
Screen material :
steel bar, steel plate punch hole, steel wire woven, stainless steel
Dimension :
according to capacity
Installation :
supply manual to guide user
Capacity :
50-500 tons per hour
Feeding size :
less than 300mm
Color :
yellow, white, red, blue, gray( or as client request)
Price :
$4,100.00 - $28,750.00/sets
MOQ :
1 unit
Description

Drum scrubber washer / mobile compost plant for fertilizer

Product Description

Composting is an effective application method in the treatment of agricultural solid wastes, such as plant residues, composting of crop straws, agricultural processing wastes, and postage fertilizers for livestock and poultry manure. The Compost drum screen for organic fertilizer is designed to improve the screening rate of these fertilizers. The emergence of Compost drum screen for organic fertilizer has great economic benefits.

Working principle of the Compost drum screen
During the use of the Compost drum screen for organic fertilizer, it runs slowly and evenly, has small impact vibration, stable work, simple installation, and sometimes does not even need a special foundation. Can be placed directly on the flat floor or floor and under the silo. The roller screen can be provided with a comb-type cleaning mechanism. During the sieving process, the relative movement of the comb-type cleaning mechanism and the screening cylinder can be used to achieve the effect of uninterrupted cleaning of the screen body, so that the screening cylinder can be used in the entire working process Always keep clean, non-sticky, non-blocking, and not affect the screening effect.

Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch HoleTopsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole

Application:munlcpal solid waste,construction waste,stone,compost,wood chips,sawdust,soil,coal,river sand,refractory materials,chemiacal,etc

Technical parameter of shaftless trommel screen

Model

Capacity

Power

Screen

Discharge Size

Input Size

(m³/h)

(kw)

Diameter (mm)

Length (mm)

(mm)

(mm)

MTS0818

0-15

2.33

800

1800

0~100

≤300

MTS1022

0-30

8.8

1000

2200

0~100

≤300

MTS1230

0-60

11.4

1200

3000

0~100

≤300

MTS1550

0-90

18.4

1500

5000

0~100

≤300

Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole

Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch HoleTopsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole

Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch HoleTopsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch HoleTopsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch HoleTopsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch HoleTopsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch HoleTopsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole

Topsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch HoleTopsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch HoleTopsoil and Compost Screening Made Easy with Mobile Trommel Screen Steel Plate Punch Hole
