Steel Plate Material Drum Screen Filter for Compost Processing and Versatile Screening
Steel Plate Material Drum Screen Filter for Compost Processing and Versatile Screening
Steel Plate Material Drum Screen Filter for Compost Processing and Versatile Screening
Steel Plate Material Drum Screen Filter for Compost Processing and Versatile Screening
Steel Plate Material Drum Screen Filter for Compost Processing and Versatile Screening
Steel Plate Material Drum Screen Filter for Compost Processing and Versatile Screening
Steel Plate Material Drum Screen Filter for Compost Processing and Versatile Screening
Steel Plate Material Drum Screen Filter for Compost Processing and Versatile Screening
Steel Plate Material Drum Screen Filter for Compost Processing and Versatile Screening
Steel Plate Material Drum Screen Filter for Compost Processing and Versatile Screening
Steel Plate Material Drum Screen Filter for Compost Processing and Versatile Screening
Steel Plate Material Drum Screen Filter for Compost Processing and Versatile Screening
Specifications
Applicable Industries :
Energy & Mining
Showroom Location :
Mexico
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Marketing Type :
New Product 2020
Warranty of core components :
1 Year
Core Components :
Motor
Condition :
New
Type :
compost trommel screener
Application :
topsoil, compost, solid, municipal soild waste, glass, mulch, organics, bark, MSW, municipal solid waste
Place of Origin :
China
Brand Name :
Sinolion
Voltage :
380V/415V/440V( as client request)
Dimension(L*W*H) :
As per different model
Weight :
2200 KG
Warranty :
18 month excluding spare parts
Product name :
High quality rotary compost sifter /drum screen filter for compost
Screen material :
steel bar, steel plate, manganese steel wire woven, stainless steel
Power :
3-45KW
Dimension :
5600x2015x2010mm
Installation :
supply manual to guide user
Capacity :
1-200 tons per hour
Feeding size :
less than 300mm
Discharge size :
less than 6mm or as request
Color :
yellow, white, red, blue, gray( or as client request)
Price :
$4,100.00 - $28,750.00/sets
MOQ :
1 unit
Description

High quality rotary compost sifter /drum screen filter for compost

Shaftless trommel screen working principle:
Due to the turning and rolling of the material in the screen drum, the material stuck in the screen hole can be ejected to prevent the screen hole from being clogged. GTS series shaftless trommel screen machine mainly consists of motor, gearbox, screen drum, frame, sealing cover, inlet and outlet. The screen drum is mounted obliquely on the frame. The motor is coupled to the drum unit via a coupling through a reducer to drive the screen drum unit to rotate about its axis. After the material enters the screen drum, due to the tilting and rotation of drum screen, the material on the screen surface is turned over and rolled, so that the qualified material (the product under the sieve) is discharged through the screen, and the unqualified material (the product on the sieve) ) is discharged through the end of the screen drum.

Steel Plate Material Drum Screen Filter for Compost Processing and Versatile Screening

Application:munlcpal solid waste,construction waste,stone,compost,wood chips,sawdust,soil,coal,river sand,refractory materials,chemiacal,etc

Technical parameter of shaftless trommel screen

Model Trommeldiameter
(mm)		 Trommel length
(mm)		 Capacity
(m3/h)		 motor power(KW) Weight
(Kg)		 Dimensions
(L*W*H)
MTS0818 800 1800 ≤15 2.4 650 3.15*1.1*1.65
MTS1022 1000 2200 ≤30 8.2 2750 4.3*1.9*2.45
MTS1230 1200 3000 ≤60 10.6 3210 5.4*2.1*2.7
MTS1550 1500 5000 ≤90 20 7900 9.4*2.2*2.9

Steel Plate Material Drum Screen Filter for Compost Processing and Versatile Screening

Steel Plate Material Drum Screen Filter for Compost Processing and Versatile ScreeningSteel Plate Material Drum Screen Filter for Compost Processing and Versatile ScreeningSteel Plate Material Drum Screen Filter for Compost Processing and Versatile ScreeningSteel Plate Material Drum Screen Filter for Compost Processing and Versatile ScreeningSteel Plate Material Drum Screen Filter for Compost Processing and Versatile Screening

Steel Plate Material Drum Screen Filter for Compost Processing and Versatile ScreeningSteel Plate Material Drum Screen Filter for Compost Processing and Versatile ScreeningSteel Plate Material Drum Screen Filter for Compost Processing and Versatile Screening Steel Plate Material Drum Screen Filter for Compost Processing and Versatile Screening
