Energy Mining Rotary Shaftless Trommel Screening Garbage Machine for Soil Separation
Energy Mining Rotary Shaftless Trommel Screening Garbage Machine for Soil Separation
Energy Mining Rotary Shaftless Trommel Screening Garbage Machine for Soil Separation
Energy Mining Rotary Shaftless Trommel Screening Garbage Machine for Soil Separation
Energy Mining Rotary Shaftless Trommel Screening Garbage Machine for Soil Separation
Energy Mining Rotary Shaftless Trommel Screening Garbage Machine for Soil Separation
Energy Mining Rotary Shaftless Trommel Screening Garbage Machine for Soil Separation
Energy Mining Rotary Shaftless Trommel Screening Garbage Machine for Soil Separation
Energy Mining Rotary Shaftless Trommel Screening Garbage Machine for Soil Separation
Energy Mining Rotary Shaftless Trommel Screening Garbage Machine for Soil Separation
Specifications
Applicable Industries :
Energy & Mining
Showroom Location :
None
Condition :
New
Type :
Gravity Separator
Production Capacity :
98%
Place of Origin :
Henan, China
Brand Name :
Sinolion
Voltage :
380V/415V/440V( as client request)
Dimension(L*W*H) :
As per different model
Weight :
2200 KG, 6.5-10T
Warranty :
24 months excluding spare parts
Marketing Type :
New Product 2021
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Core Components :
Motor
Key Selling Points :
mobile gold washing trommel
Product name :
Rotary shaftless trommel screening garbage machine for sale
Model :
trommel screening garbage machine
Power :
5.5KW, 7.5KW, 11KW
Dimension :
depends on model
Application :
alluvial gold washing, diamond, rock, soil, river gold
Capacity :
30-150 tons per hour
Feeding size :
less than 300mm
Discharge size :
less than 6mm
Color :
yellow, white, red, blue, gray( or as client request)
Price :
$30,000.00/sets 1-1 sets
MOQ :
1 unit
Description

Rotary shaftless trommel screening garbage machine for sale

Product Description

Energy Mining Rotary Shaftless Trommel Screening Garbage Machine for Soil Separation

Shaftless trommel screen working principle:
Due to the turning and rolling of the material in the screen drum, the material stuck in the screen hole can be ejected to prevent the screen hole from being clogged. GTS series shaftless trommel screen machine mainly consists of motor, gearbox, screen drum, frame, sealing cover, inlet and outlet. The screen drum is mounted obliquely on the frame. The motor is coupled to the drum unit via a coupling through a reducer to drive the screen drum unit to rotate about its axis. After the material enters the screen drum, due to the tilting and rotation of drum screen, the material on the screen surface is turned over and rolled, so that the qualified material (the product under the sieve) is discharged through the screen, and the unqualified material (the product on the sieve) ) is discharged through the end of the screen drum.

Energy Mining Rotary Shaftless Trommel Screening Garbage Machine for Soil Separation

Energy Mining Rotary Shaftless Trommel Screening Garbage Machine for Soil Separation

Working Principle

1. lowering initial investment cost (comparative price)

2. saving operational cost (outstanding durability and simple mechanical structure)

3. reducing any additional cost in the future (high productivity & mobility)

4. GTS series can precisely select gold dust in highest yield rate of 98%.

5. High gold dust gathering capability by long-time and non-stop operation

technical parameters

Model Capacity (t/h) Motor (kw) Drum size (mm) Feed Size (mm) Overall size (mm) Weight (KG)
GTS-1015 5-20 3 1000×1500 less than 200 mm 2600×1400×1700 2200
GTS-1020 10-30 4 1000×2000 less than 200 mm 3400×1400×2200 2800
GTS-1225 20-80 5.5 1200×2500 less than 200 mm 4200×1500×2680 4200
GTS-1530 30-100 7.5 1500×3000 less than 200 mm 4500×1900×2820 5100
GTS-1545 50-120 11 1500×4500 less than 200 mm 6000×1900×3080 6000
GTS-1848 80-150 15 1800×4800 less than 200 mm 6500×2350×4000 7500
GTS-2055 120-250 22 2000×5500 less than 200 mm 7500×2350×4800 9600
GTS-2265 200-350 30 2200×6500 less than 200 mm 8500×2750×5000 12800

Energy Mining Rotary Shaftless Trommel Screening Garbage Machine for Soil SeparationEnergy Mining Rotary Shaftless Trommel Screening Garbage Machine for Soil Separation

Packaging & Shipping

Energy Mining Rotary Shaftless Trommel Screening Garbage Machine for Soil Separation

Case

Energy Mining Rotary Shaftless Trommel Screening Garbage Machine for Soil Separation

Customer

Energy Mining Rotary Shaftless Trommel Screening Garbage Machine for Soil Separation

Company Information

Energy Mining Rotary Shaftless Trommel Screening Garbage Machine for Soil SeparationEnergy Mining Rotary Shaftless Trommel Screening Garbage Machine for Soil SeparationEnergy Mining Rotary Shaftless Trommel Screening Garbage Machine for Soil SeparationEnergy Mining Rotary Shaftless Trommel Screening Garbage Machine for Soil Separation
