Specifications
Brand Name :
Lianti
Model Number :
KDW-3582(1:1)
Certification :
ISO9001
Place of Origin :
Jiangsu, China
MOQ :
1.0 Barrels
Packaging Details :
25KG/drum; etc.
CAS No. :
63148-60-7
Other Names :
Silicone Sealant
EINECS No. :
Unspecified
Classification :
Double Components Adhesives
Main Raw Material :
Silicone
Usage :
Eletronics
Type :
Additional
Application :
Eletronics
Certificate :
ISO9001
Color :
White/Gray
Appearance :
Paste
Features :
High thermal conductivity
Packaging :
25KG
viscosity :
Low viscosity
Shelf life :
1 year
Description

Kangdawei electronics potting high thermal conductivity silicone rtv adhesive compound with high quality

About us

Low Viscosity Rtv Silicone Potting Compound For Electronics Easy To Process

Production Features

KDW-3582(1:1) is used on all kinds of componets of potting sealing and protection. It can be deeply cured, and with good liquidity, UV resistance, weather resistance, rain resistance and dirt resistance after mixed. And it can serve for a long time on outdoor products of fixation, waterproof, dustproof and anticreep.
1. Two components silicone pouring compound, additional type
2. Low viscosity, easy to process, strong maneuverability
3. Low shrinkage rate, no corrosion, no stress
4. Excellent high temperature electrical insulation, thermal conductivity and stability
5. Good waterproof and dampproof performance

Technical Data

Property
Unused
Used
A
B
Uncured
Color
White/Gray
White
White/Gray
Viscosity (mpa·s)
4800
4600
4700
Density (g/cm³)
1.50~1.60
1.50~1.60
1.50~1.60
Allowable operating time (25℃, min)
10-30
Complete cured time (25℃,h)
8-12
Cured
Tensile strength (Mpa)
≥1.0
Elongation (%)
≥100
Shore hardness (A)
60
Volume resistivity (Ω·cm)
≥1 X 1014
Dielectric strength (KV/mm)
≥20
Thermal stability (℃)
-50~+250
Linear shrinkage (%)
≤0.5
Thermal conductivity
0.8
Flame retardant rating
UL94V-0
Ps: Operation time is tested based on 100g adhesive.
All data was measured by testing after 7 days curing under the condition of 25℃ and 55%RH.
Operation

1. Weighing component A and B according to the ratio of 1:1, stirring evenly after mixed, then inject it to components and module which needed to be potting protected. It would be better to injected along one side of the wall, which can reduce the generation of air bubbles.
2. Placing the sealed component, and it would discharge bubbles by itself, if possible, vacuumizing and defoaming the mixed rubber before potting sealing. Directly cured at room temperature, usually the rubber will have elasticity within 1-6 hours.
