ODM 3:1 Clear Resin Epoxy Potting Compound Glue For LED Driver 2 Parts
ODM 3:1 Clear Resin Epoxy Potting Compound Glue For LED Driver 2 Parts
Specifications
Brand Name :
Hanast
Model Number :
HN-5508AB
Certification :
ROHS SGS
MOQ :
1KG
Price :
Negotiable
Payment Terms :
T/T
Packaging Details :
25KG/barrel
Color :
Clear
Mix Ratio :
1:1
Operating Temperature Range :
-40°C to 130°C
Viscosity :
5000-10000 cps
Dielectric Strength :
500 V/mil
Density :
1.71±0.05，g/cm3
Specific Gravity :
1.2
Shelf Life :
1 year
Hardness :
Shore D 85
Appearance :
Semi-solid
Pot Life :
30 minutes
Thermal Conductivity :
1.2 W/mK
Chemical Resistance :
Excellent
Cure Time :
24 hours
Tensile Strength :
5000 psi
Description

3:1 Epoxy Resin Potting Glue for LED Driver Transformers Resistors Power Module High Hardness 2 Parts Transparent Potting Glue Compound

Product Description:

HN-5508 epoxy resin at room temperature or low temperature, with low viscosity, long operation time, good fluidity, and easy penetration into the clearance of the product; no bubbles after curing, smooth surface, luster, high hardness

Main Features:

Flame retardant insulation, sealing bonding, moisture-proof earthquake resistance, temperature resistance

ODM 3:1 Clear Resin Epoxy Potting Compound Glue For LED Driver 2 Parts

Before curing

builder

Epoxy resin 5508

Curing agent 5508

pigment

Black / White et al

Ruburn / transparent surface

A sticky epoxy resin water

r liquid specific

c gravity, g / cm3

1.4-1.5

1.05

Viscosity of 25℃

4,500—6,000cp s

150—250cp storage

e Period (25℃)

Six months

x months

processabili

mixing ratio

A: B =5:1 (weight ratio)

Available for a time of 25℃

2-3H (100g mix)

curing time

25℃ / 6-8H surface stem, 12-16H fully cured or 60-80℃/1.5-2H

After curing

2 Tensile strength of kg/cm

16-18

2 Compressive strength of kg/cm

18-22

Resistance to the voltage of kv/mm

20-22

Surface resistance ofΩ-cm

14

1.2*10

Volume resistance ofΩ-cm

15

1.1*10

contraction percentage%

0.35-0.55

Water absorption rate was 25℃ * 24H

<0.03%

The hardness of SHORE A

85-95

distortion

temperature ℃

130-150

low temperature resistant ℃

-30

Applications:

ODM 3:1 Clear Resin Epoxy Potting Compound Glue For LED Driver 2 Parts

ODM 3:1 Clear Resin Epoxy Potting Compound Glue For LED Driver 2 Parts

storage and transportation

1. Store in a cool and dry place with a storage period of 6 months (25℃).

2. Products beyond the storage period should be confirmed whether there are any abnormalities before being used.

3. Parts A and B of the colloid must be sealed and preserved, with careful leakage during transportation!

4. These kinds of products are non-dangerous goods and can be transported as general chemicals.
