Specifications
Brand Name :
Hanast
Model Number :
HN-5508A/B
Certification :
ROHS，SGS
Place of Origin :
Guangdong, China
MOQ :
1 kilogram
Price :
Negotiable
Payment Terms :
T/T, D/A, D/P
Delivery Time :
5-7days
Packaging Details :
25KG/ Iron Drum
Name :
Flexible Epoxy Potting Compound
Color :
Black,clear
Curing time :
25℃ / 6-8H surface stem, 12-16H fully cured or 60-80℃/1.5-2H
Mix ratio :
A: B =5:1 (weight ratio)
Resistance to the voltage of kv/mm :
20-22
Hardness :
85-95 shore D
Feature :
flame retardant insulation
Application :
transformers, resistors, filters, temperature sensors
Shelf time :
6month
Tensile strength of kg/cm :
16-18
Description

Electrical Epoxy Potting Material Black Clear High-Temperature Epoxy Potting Adhesive Potting Compound For Led Driver Power Module

Product description of Epoxy Potting Adhesive

Epoxy potting compound is a liquid polymer material primarily composed of epoxy resin, along with curing agents, fillers, and functional additives. It is used in fields such as electronic components and precision instruments to provide insulation, sealing, moisture resistance, dust protection, and shock resistance. After curing, it forms a hard, high-performance insulator and is widely used in the electronics, automotive, and new energy industries.

Electrical Epoxy Potting Material Black Clear High-Temperature Epoxy Potting Adhesive Potting Compound For Led Driver Power Module

Product features of Epoxy Potting Adhesive
Electrical insulation, waterproofing and moisture resistance, dustproof, corrosion resistance, high and low temperature resistance, vibration resistance, improved mechanical strength, and confidentiality.

Electrical Epoxy Potting Material Black Clear High-Temperature Epoxy Potting Adhesive Potting Compound For Led Driver Power Module

Electrical Epoxy Potting Material Black Clear High-Temperature Epoxy Potting Adhesive Potting Compound For Led Driver Power Module


Physical Properties of epoxy potting adhesive

efore curing builder Epoxy resin 5508 Curing agent 5508
pigment Black / White et al Ruburn / transparent surface
A sticky epoxy resin water r liquid specific
c gravity, g / cm3 1.4-1.5 1.05
Viscosity of 25℃ 4,500—6,000cp s 150—250cp storage
e Period (25℃) Six months x months

processabili

 mixing ratio A: B =5:1 (weight ratio)
Available for a time of 25℃ 2-3H (100g mix)
curing time 25℃ / 6-8H surface stem, 12-16H fully cured or 60-80℃/1.5-2H
After curing 2 Tensile strength of kg/cm 16-18
2 Compressive strength of kg/cm 18-22
Resistance to the voltage of kv/mm 20-22
Surface resistance ofΩ-cm

14

1.2*10
Volume resistance ofΩ-cm

15

1.1*10
contraction percentage% 0.35-0.55
Water absorption rate was 25℃ * 24H <0.03%

The hardness of SHORE A 85-95

distortion

temperature ℃

 130-150
low temperature resistant ℃ -30


Application Scenarios of epoxy potting adhesive
Electronics and Electrical Appliances: Circuit boards, LED power supplies, sensors, capacitors, etc.
Automotive/New Energy: Electronic control units, igniters, motors.
Other: Aerospace, instrumentation, etc.

Package:

This product is 40KG per group;

Component A is 20KG (in barrels), and Component B is 20KG (in barrels)
