Polyethylene Navigation Buoy Large Diameter PE Marine Channel Marking Buoy
Polyethylene Navigation Buoy Large Diameter PE Marine Channel Marking Buoy
Polyethylene Navigation Buoy Large Diameter PE Marine Channel Marking Buoy
Polyethylene Navigation Buoy Large Diameter PE Marine Channel Marking Buoy
Polyethylene Navigation Buoy Large Diameter PE Marine Channel Marking Buoy
Polyethylene Navigation Buoy Large Diameter PE Marine Channel Marking Buoy
Polyethylene Navigation Buoy Large Diameter PE Marine Channel Marking Buoy
Polyethylene Navigation Buoy Large Diameter PE Marine Channel Marking Buoy
Polyethylene Navigation Buoy Large Diameter PE Marine Channel Marking Buoy
Polyethylene Navigation Buoy Large Diameter PE Marine Channel Marking Buoy
Polyethylene Navigation Buoy Large Diameter PE Marine Channel Marking Buoy
Polyethylene Navigation Buoy Large Diameter PE Marine Channel Marking Buoy
Specifications
Brand Name :
DOOWIN MARINE
Model Number :
SBM
Certification :
BC, LR, ABS, CCS
Place of Origin :
China
MOQ :
1pc
Price :
70 ~ 3000 $USD
Payment Terms :
T/T
Supply Ability :
10pcs/per week
Delivery Time :
2~3 weeks
Packaging Details :
Pallet or Plywooden Box
Product Name :
Polyethylene Navigation Buoy Ocean Floating Buoy Large Diameter PE Marine Channel Marking Buoy
Material :
PE filled closed cell foam
Brand :
DOOWIN
Weight :
According to different user's water working deepth
Water deepth :
Withstands extreme depths up to 7000m without structural failure.
Density range :
0.3-0.7g/cm³
Lifespan :
20 years
Color/Size :
As per customer request
Submersible Depth :
<= 11,000 meters
Description
Polyethylene Navigation Buoy Ocean Floating Buoy Large Diameter PE Marine Channel Marking Buoy

● Pressure and corrosion resistance ● High density and low water absorption

● High strength and pressure resistance ● Customizability

Spherical floats are essential equipment for deep-sea exploration and operations. Their key components include solid buoyancy materials. These materials, with their low density, high strength, and corrosion resistance, play an irreplaceable role in deep-sea floats and other deep-sea equipment.

Polyethylene Navigation Buoy Large Diameter PE Marine Channel Marking Buoy

Spherical floats are devices that maintain stable buoyancy in deep-sea environments. They are typically made of lightweight, pressure-resistant composite materials and filled with solid buoyancy materials to ensure stable buoyancy in the high-pressure, high-salinity, and low-light environments of the deep sea. Deep-sea floats not only provide buoyancy for deep-sea research equipment but can also serve as deep-sea instrument chambers, carrying various scientific instruments and equipment for deep-sea exploration and experiments.

Spherical floats come in various types depending on their material, purpose, and specifications. For example, deep-sea glass floats are made of glass, offering extremely high compressive strength and transparency; others are made of materials such as plastic and polyurethane, offering advantages such as low cost and ease of processing. Furthermore, the diameter, buoyancy, and other specifications of deep-sea floats can be customized to meet specific needs.

Key Features
  • Polyurethane Elastomer Skin - Available in various high-visibility colors
  • Self-fendering design with high impact absorption capability
  • Multiple end fitting options for different applications
  • Fully customizable in size and shape to meet specific requirements
Polyethylene Navigation Buoy Large Diameter PE Marine Channel Marking Buoy
Construction Details
  • Inner Foam Core: Unsinkable closed-cell polyethylene/EVA foam core with various densities
  • Reinforcement Layer: Optional nylon reinforcement for enhanced tear strength
  • Outer Skin: UV-resistant, high-visibility polyurethane elastomer skin

    Applications

    Primary Applications
    • Deep-sea exploration: Carrier for deep-sea probes and scientific instruments
    • Ocean monitoring: Water quality and pollution monitoring applications
    • Channel warning: Navigation safety marking for marine vessels
    Industry Applications
    • Underwater robots: Provides essential buoyancy support
    • Submersibles: Key component for buoyancy balance
    • Buoy systems: Maintains stable suspension at predetermined depths
    • Offshore oil exploration: Used in risers and deepwater pipeline floats
    • Marine survey systems: ADCPs and seabed-based floats
    • Marine mining systems: Cable floats and trencher floats
Subsea Buoyancy Foam Specifications

Type

Model

Density

(g/cm3)

Compression Strength

(MPA)

Water Absorption

(24 hours)

Submersible Depth

(m)

Chemical Foam

CSBM-08

0.08

/

≤5%

Surface

Chemical Foam

CSBM-020

0.20

0.5

≤5%

50

Chemical Foam

CSBM-025

0.25

1

≤5%

100

Chemical Foam

CSBM-030

0.30

2

≤5%

200

Standard Performance

SBM-36

0.36 ± 0.01

≥ 16

≤1%

500

Standard Performance

SBM-38

0.38 ± 0.01

≥ 21

≤1%

800

Standard Performannce

SBM-43

0.43 ± 0.02

≥ 24

≤1%

1 000

Standard Performance

SBM-45

0.45 ± 0.02

≥ 28

≤1%

1 500

Standard Performannce

SBM-51

0.51 ± 0.02

≥ 45

≤1%

3 000

Standard Performance

SBM-54

0.54 ± 0.02

≥ 60

≤1%

4 000

Standard Performannce

SBM-58

0.58 ± 0.02

≥ 75

≤1%

5 000

Standard Performance

SBM-63

0.63 ± 0.02

≥ 90

≤1%

6 000

Standard Performannce

SBM-70

0.70 ± 0.02

≥ 145

≤1%

11 000

High Performance

SBM-43H

0.42 ± 0.02

≥ 27

≤1%

1 800

High Performance

SBM-45H

0.45 ± 0.02

≥ 35

≤1%

2 000

High Performance

SBM-48H

0.48 ± 0.02

≥ 42

≤1%

3 000
Production Process
