Specifications
Brand Name :
Gnee
Certification :
SGS
Place of Origin :
Henan
MOQ :
10 Ton
Supply Ability :
10000 Ton/Tons per Month
Packaging Details :
Standard Sea Worthy Package
Description

What is hot dip galvanizing steel?
Hot dip galvanizing is to first pickling the steel to remove the iron oxide on the surface of the steel, after pickling, through ammonium chloride or zinc chloride aqueous solution or ammonium chloride and zinc chloride mixed aqueous solution for cleaning, and then into the hot dip plating tank to complete galvanizing. The molten zinc reacts with the iron matrix to form an alloy layer, which binds the substrate to the coating. Usually used in construction, home appliances, automobiles, power industry and other fields.


Prime JIS G3302 Standard Hot Dipped Galvanized Steel Coil with Z275 Coating and 0.3-3.0mm Thickness


Thick 0.3 ~3.0 mm
Width 600-1500 mm
Zinc Coating 30~275G/M2
Coil ID 508 / 610MM
Coil Weight 3-5 Tons
Standard ASTM-A653; JIS G3302; EN10147; EN10326etc
Payment Terms T/T, LC,DP.
Regular Order 25 tons or one container, for less quantity, to contact with us for details
Hardness Soft hard(HRB60),medium hard(HRB60-85),full hard(HRB85-95)
Surface Structure Regular spangle,Minimum spangle, Zero spangle, Big spangle
Surface Treatment Chromated/Non-Chromated, Oiled/Non-oiled, Skin pass


1.Standard

Content
Material: SG550/SG280/SG350DX51D+Z SGCC/ CS TYPE
Finish NBMinimized Spangle (M)
Surface Treatment Chemically Passivated (C)
Oil Not Oiled
Zinc Z30--275
Thickness tolerances Normal thickness tolerances 0.40 < thickness ≤ 0.60 ± 0.060
0.60 < thickness ≤ 0.80 ± 0.070
0.80 < thickness ≤ 1.00 ± 0.080
1.00 < thickness ≤ 1.20


Width tolerances
1200 < width ≤ 1500 6 ~ 0


2. Chemical composition

Designation Chemical composition % by mass max.
Steel grade
C Si Mn P S TI
Steel name Symbols for the types of available coatings
DX51D +Z 0.18 0.5 1.2 0.12 0.045 0.3


Prime JIS G3302 Standard Hot Dipped Galvanized Steel Coil with Z275 Coating and 0.3-3.0mm Thickness
