Hot Dipped Galvanized Steel Grating Stair Tread Grid with ASTM A36 Q235 and Stainless Steel 304 Options
Hot Dipped Galvanized Steel Grating Stair Tread Grid with ASTM A36 Q235 and Stainless Steel 304 Options
Hot Dipped Galvanized Steel Grating Stair Tread Grid with ASTM A36 Q235 and Stainless Steel 304 Options
Hot Dipped Galvanized Steel Grating Stair Tread Grid with ASTM A36 Q235 and Stainless Steel 304 Options
Hot Dipped Galvanized Steel Grating Stair Tread Grid with ASTM A36 Q235 and Stainless Steel 304 Options
Hot Dipped Galvanized Steel Grating Stair Tread Grid with ASTM A36 Q235 and Stainless Steel 304 Options
Specifications
Brand Name :
Gnee
MOQ :
2PCS
Supply Ability :
300000 Square Meter/Square Meters per Month
Delivery Time :
Shipped in 20 days after payment
Packaging Details :
Fix with metal belt Packing with pallet ,outside wrap with waterproof plastic film Finial in container
Description
Best Price Hot Dipped Galvanized Steel Grating Stair Tread Grid

Steel Grating is welded from bearing steel bars and cross twisted bars according to required pitch spacing between steel bars using specialized welding machines. This grid building material offers exceptional strength and durability for various industrial applications.

All gratings are manufactured using high-quality standard steel materials that provide excellent hardness and high tensile strength. The product features:

  • Extreme durability and load-bearing capacity
  • Superior corrosion resistance
  • Excellent anti-slip performance
  • Customizable specifications based on application requirements

Available in a range of spacing pitch, thicknesses, and heights to meet specific load-bearing requirements for different installation environments.

Hot Dipped Galvanized Steel Grating Stair Tread Grid with ASTM A36 Q235 and Stainless Steel 304 Options
Standard Specifications
Material Standard ASTM A36, A1011, A569, Q235, S275JR, Stainless steel 304, Mild steel & Low carbon steel, etc
Bearing Bar (width*thickness) 25x3, 25x4, 25x4.5, 25x5, 30x3, 30x4, 30x4.5, 30x5, 32x5, 40x5, 50x5, 65x5, 75x6, 75x10, 100x10mm, etc;
I bar: 25x5x3, 30x5x3, 32x5x3, 40x5x3, etc
US standard: 1''x3/16'', 1 1/4''x3/16'', 1 1/2''x3/16'', 1''x1/4'',1 1/4''x1/4'', 1 1/2''x1/4'', 1''x1/8'', 1 1/4''x1/8'', 1 1/2''x1/8'', etc
Bearing Bar Pitch 12.5, 15, 20, 23.85, 25, 30, 30.16, 30.3, 32.5, 34.3, 35, 38.1, 40, 41.25, 60, 80mm etc.
US standard: 19-w-4, 15-w-4, 11-w-4, 19-w-2, 15-w-2 etc.
Twisted Cross Bar Pitch 38.1, 50, 60, 76, 80, 100, 101.6, 120mm, 2'' & 4'' etc
Surface Treatment Untreated (black), hot-dipped galvanized, powder coated, electroplate, painting or as per customers' requirement
Grating Style Plain / Smooth, Serrated / teeth, I bar, serrated I bar

Customization available: We can manufacture steel gratings according to your unique specifications, drawings, or special size requirements for your project.
