Specifications
Brand Name :
Gnee
MOQ :
2PCS
Supply Ability :
300000 Square Meter/Square Meters per Month
Delivery Time :
Shipped in 20 days after payment
Packaging Details :
Fix with metal belt Packing with pallet ,outside wrap with waterproof plastic film Finial in container
Description

Steel bar grating with high strength and firm structure is made up of carbon steel, aluminum steel, or stainless steel. According to the manufacturing methods, it can be divided into four types: welded, press-locked, swage-locked, and riveted gratings. According to the surface shapes, it can be divided into smooth and serrated gratings. With various styles and sizes for choice, steel gratings are widely used in everyday life, such as stair treads, walkways, platforms, floors, various covers, wheeled equipment, security screens, heavy-duty constructions, and so on.


Product Name
Steel Grating
Specification
200*500*30,200*1000*20,200*1000*30,250*500*20,250*500*30,250*1000*20,250*1000*30,300*500*20,300*500*30,300*1000*20,300*1000*30,350*500*30,350*1000*30,400*600*30,400*1000*30,400*1000*60
Product Material
Q235/Q345 Carbon Steel/ Stainless steel
Grating Style
Plain/Smooth,Serrated /Teeth,l bar, Serrated I bar
Surface Treatment
Hot-dipped galvanized, Powder coated, Electroplate, Untreated(black), Painting or as per customers' requirement.
Sheet Thickness
3/4/5/6/8/9/10mm
Standard
China: YB/T 4001.1-2007
USA: ANSI/NAAMM(MBG531-88)
UK: BS4592-1987
Australia: AS1657-1985
Application
Platform, Walkway, Trestle, Ditch Cover, Manhole Cover, Ladder,Fence, etc
Warranty
5 Years


Steel Grating Accessories for Installing
Steel grating accessories are used to install and fix steel grating. They are very necessary. Steel grating accessories have wear resistance, high strength and resistance to stress, rust-proof performance.
Classifications of steel grating accessories:
Saddle clips: A special bent-clip type fastener for removable bar grating panels.
G-clips: A special friction fastener can be used with aluminum, stainless steel and galvanized steel.
Grate fast clips: Grating can be connected by one man only, working from above, without the need to drill the steel or weld on site.
Weld lugs: Weld lugs may be used for installations where grating is subject to removal.
Z-clip: This is the most versatile clip anchor. They are especially helpful in holding down riveted grating.
R-clip: A special formed metal fastener available in various sizes to fit any job.
Countersunk land: It is available for aluminum grating only. Not available for steel.
Anchor block: It can be used to fasten permanent or removable grating panels.
