Specifications
Brand Name :
GNEE
Certification :
SGS
Place of Origin :
China
Price :
Negotiable
Payment Terms :
Negotiable
Supply Ability :
100 ton/week
Delivery Time :
5-9 working days
Packaging Details :
Sea-worthy packing, ie wooden or steel tray with steel strip,etc
Description
Leading Manufacturer of Galvanized Steel Coil Offering Full Range of Sizes and Coating Classes
Hot Dipped Galvanized Steel Coil

Galvanized steel coil is a type of steel coil that has undergone surface galvanizing treatment. It is coated with a layer of zinc on the surface of a substrate (such as cold-rolled or hot-rolled steel plate) to improve its corrosion resistance and service life. The galvanizing process mainly includes two methods: hot-dip galvanizing (hot-dip galvanizing) and electroplating galvanizing. Among them, hot-dip galvanizing is more common, with a thicker zinc layer and stronger protection.

Leading Manufacturer of Galvanized Steel Coil Offering Full Range of Sizes and Coating Classes
Product Name Hot Dipped Galvanized Steel Coil Surface Big/Regular/Zero/Bright Spangle
Thickness 0.12-4.0mm Type Coil Sheet Strip
Width 900-1250mm; Strip:20-600mm Coil ID. 508/610mm
Zinc Coating 20-275g/m2 Service Welding Pipe,Cutting Length,Slitting Strip
Garden DX51D,DX52D,SGCC,GB,ASTM A653,JIS,G3302 Test report Provide
Leading Manufacturer of Galvanized Steel Coil Offering Full Range of Sizes and Coating Classes
Advantages of Galvanized Steel
  • Excellent corrosion resistance, zinc has more reactive chemical properties than iron and will preferentially react with oxygen and water vapor in the environment to form a dense oxide film. The service life of galvanized steel plates can reach 10-50 years, far exceeding that of ordinary steel plates.
  • High cost-effectiveness and low cost anti-corrosion: Compared with stainless steel or other alloy steels, galvanizing process has lower cost, but can significantly improve the durability of steel plates and reduce maintenance or replacement costs.
  • Good processing performance, galvanized steel sheet can be processed by cutting, bending, welding, etc.
  • High strength and lightweight, different strength substrates (such as low bon steel and high-strength steel) can be selected according to needs.
  • Aesthetics, the galvanized layer presents a silver gray luster, neat and beautiful, suitable for exposed use occasions.
  • Environmental friendliness and recyclability: Galvanized steel plates are 100% recyclable, and zinc itself is also a reusable resource.
Available Steel Grade (Ensure weight and support third-party testing)
Steel grade Coating Yield(MPA) Tensile(MPA) Elongation(%)
DX51D Z,ZF -- 270-500 20
DX52D Z,ZF 140-300 270-420 22
DX53D Z,ZF 140-260 270-380 26
DX54D Z,ZF 140-220 270-350 30
S220GD Z,ZF 220 300 18
S250GD Z,ZF 250 330 17
S280GD Z,ZF 280 360 16
S320GD Z,ZF 320 390 15
S350GD Z,ZF 350 420 14
S400GD Z,ZF 400 470 --
S450GD Z,ZF 450 530 --
S500GD Z,ZF 500 560 --

Select type Galvanized Steel based on requirements
